Parameters Listed By Linear Number - Rockwell Automation PowerFlex 7000 Technical Data Manual

Name
1 Input Ctctr Cfg
3 Auto Restart Dly
4 Operating Mode
5 Output Ctctr Cfg
7 Speed Ref Select
8 Drv Fault6 Mask
9 Drive Fault6
10 InpCtctr OpenDly
11 Passcode 0
12 Passcode 1
13 Setup Wizard
14 Liquid Outputs
15 Line Cap kVAR
16 Line Cap Volts
17 Rated Line Freq
18 Rated Line Volts
19 Rated Drive Amps
20 Motor Cap kVAR
21 Motor Cap Volts
22 Rated Motor Volt
23 Rated Motor Amps
24 Rated Motor kW
25 Rated Motor HP
26 Rated Motor RPM
27 DCLnk Inductance
28 Motor Cap Freq
29 Rated Motor Freq
30 Motor Type
31 Service Factor
32 Line Cap Freq
33 Preset Speed 1
34 Preset Speed 2
35 Preset Speed 3
36 Profile Mask
37 Profile Owner
38 Passcode 2
39 Passcode 3
40 Preset Jog Speed
41 RefCmd Pot Min
42 RefCmd Pot Max
43 RefCmdAnlgInpMin
44 RefCmdAnlgInpMax
45 RefCmd DPI Min
46 RefCmd DPI Max
47 SpdCmd Pot
48 SpdCmd Anlg Inp1
49 Skip Speed 1
50 Skip Speed 2
51 Skip Speed 3
52 Liquid Inputs

Parameters Listed by Linear Number

Min. Max.
- -
0.0 10.0
- -
- -
- -
- -
- -
0.0 60.0
0 65535
0 65535
- -
- -
1 7500
100 10000
50 60
100 7200
10 1750
1 7500
100 10000
100 8000
10 1500
10 15000
10 20000
150.0 3600.0
1.0 500.0
50 90
25 90
- -
0.75 1.25
50 60
0.5 75.0
0.5 75.0
0.5 75.0
- -
- -
0 65535
0 65535
1.0 60.0
-120.0 120.0
0.0 120.0
-120.0 120.0
0.0 120.0
0.0 120.0
0.0 120.0
-120.0 120.0
-120.0 120.0
1.0 90.0
1.0 90.0
1.0 90.0
- -
Parameters Listed by Linear Number
Default
All Faults
0.0
Normal
Not Running
Local
1111111111111111
-
0.0
-
-
0000000000000000
-
400
4160
60
4160
159
400
4160
4000
159
933
1250
1192.0
24.0
60
60
Induction
1.00
60
30.0
35.0
40.0
11111111
-
-
-
6.0
6.0
60.0
6.0
60.0
6.0
60.0
-
-
90.0
90.0
90.0
-
2-219
Read-
Units Access
Only
N Basic
sec N Basic
N Monitor
N Basic
N Monitor
N Service
Y Service
min N Advanced
Y Monitor
Y Monitor
N Service
Y Service
kvar N Service
V N Service
Hz N Service
V N Service
A N Service
kvar N Service
V N Service
V N Basic
A N Basic
kW N Basic
hp N Basic
RPM N Basic
mH N Service
Hz N Service
Hz N Basic
N Service
N Basic
Hz N Service
Hz N Advanced
Hz N Advanced
Hz N Advanced
N Basic
Y Monitor
Y Monitor
Y Monitor
Hz N Basic
Hz N Basic
Hz N Basic
Hz N Basic
Hz N Basic
Hz N Basic
Hz N Basic
Hz Y Basic
Hz Y Basic
Hz N Advanced
Hz N Advanced
Hz N Advanced
Y Service
7000-TD002A-EN-P – September 2007
