Rockwell Automation PowerFlex 7000 Technical Data Manual page 265

Name
111 RecHSink TempTrp
112 RecHSink TempWrn
113 CurReg Bandwidth
114 DCLnk Induct pu
115 T DC Link
116 DC Link Current
117 Bypass Voltage
118 Control AC#1 RMS
119 Idc Test Command
120 Idc Ref Step
121 Control 56V
122 Line Current pu
123 Anlg Out4 Scale
124 Anlg RecTstPt3
125 Anlg RecTstPt4
126 Anlg InvTstPt3
127 Anlg InvTstPt4
128 Motor Filter Cap
129 R Stator
130 L Total Leakage
131 Lm Rated
132 T Rotor
133 Line Filter Cap
134 Lm Measured
135 Line Voltage pu
136 Master Line Volt
137 Slave1 Line Volt
138 Slave2 Line Volt
139 Control 5V
140 Input Impedance
141 HardwareOptions1
142 Control 15V
143 InvDvc CurRating
144 RecDvc CurRating
145 Series RecDvc
146 Series InvDvc
147 Active Trq Limit
148 DPI Loss Warning
149 CT Ratio Line
150 HECS Ratio Motor
151 CT Brden Line
152 HECS Brden Motor
153 Rectifier Type
154 Inv PWM Max Freq
155 Rec PWM Max Freq
156 Control HECS
157 CT Ratio Gndflt
158 CT Burden Gndflt
159 Bypass Frequency
160 RecControl Flag2
161 Line OvrCur Trp
162 Line OvrCur Dly
163 Drv OvrLoad Trp
164 Drv OvrLoad Dly
165 Line OvrVolt Trp
166 Line OvrVolt Dly
Min. Max. Default
0 100 55
0 100 53
50.0 2000.0 200.0
0.00 10.00 -
0.015 0.150 0.040
0 999 -
0.000 2.000 -
0.0 300.0 -
0.000 1.500 0.000
0.000 1.000 0.000
0.0 72.0 -
0.000 4.000 -
0.00 655.35 1.00
0 779 326
0 779 700
0 779 291
0 779 306
0.00 2.00 -
0.0000 0.5000 0.0000
0.00 0.75 0.25
1.00 15.00 3.50
0.10 10.00 1.50
0.00 2.00 -
0.00 15.00 -
0.000 2.000 -
0.000 2.000 -
0.000 2.000 -
0.000 2.000 -
0.0 8.0 -
0.0000 1.0000 0.0500
- - 0000000010000000
0.0 24.0 -
0 3500 800
0 3500 800
1 6 2
1 6 2
-4.000 4.000 -
- - -
10 10000 1000
10 10000 4000
1.0 100.0 5.0
1.0 100.0 50.0
- - 6 PWM
100 1000 440
100 1000 440
0.0 36.0 -
10 10000 2000
10 10000 1000
-100.0 100.0 -
- - -
0.00 4.00 1.75
0 100 10
0.00 4.00 1.15
0.0 600.0 60.0
0.00 2.00 1.20
0 1000 10
Parameters Listed by Linear Number
Read-
Units
Only
C N
C N
r/s N
pu Y
sec N
A Y
pu Y
V Y
pu N
pu N
V Y
pu Y
N
N
N
N
N
pu Y
pu N
pu N
pu N
sec N
pu Y
pu Y
pu Y
pu Y
pu Y
pu Y
V Y
pu N
N
V Y
A N
A N
N
N
Y
Y
N
N
ohms N
ohms N
N
Hz N
Hz N
V Y
N
ohms N
Hz Y
Y
pu N
msec N
pu N
sec N
pu N
msec N
7000-TD002A-EN-P – September 2007
2-221
Access
Service
Service
Advanced
Service
Advanced
Basic
Advanced
Advanced
Advanced
Advanced
Advanced
Service
Basic
Service
Service
Service
Service
Service
Advanced
Advanced
Advanced
Advanced
Service
Service
Service
Service
Service
Service
Advanced
Service
Service
Advanced
Service
Service
Service
Service
Advanced
Service
Service
Service
Service
Service
Service
Service
Service
Advanced
Service
Service
Advanced
Service
Advanced
Advanced
Advanced
Advanced
Advanced
Advanced
