Rockwell Automation Allen-Bradley PowerFlex 700S Installation Instructions Manual

What This Kit Includes
Tools That You Need
PowerFlex 700S Phase II Drives DriveLogix
Option Card Battery Extension Cable
ATTENTION: To avoid an electric shock hazard, ensure that all
!
power to the drive has been removed before performing the
following.
ATTENTION: To avoid an electric shock hazard, verify that the
!
voltage on the bus capacitors has discharged completely before
servicing. Check the DC bus voltage at the Power Terminal
Block by measuring between the +DC and -DC terminals,
between the +DC terminal and the chassis, and between the -DC
terminal and the chassis. The voltage must be zero for all three
measurements.
ATTENTION: HOT surfaces can cause severe burns. Do not
!
touch the heatsink surface during operation of the drive. After
disconnecting power allow time for cooling.
ATTENTION: Hazard of permanent eye damage exists when
!
using optical transmission equipment. This product emits intense
light and invisible radiation. Do not look into SynchLink
fiber-optic ports or SynchLink fiber-optic cable connectors.
ATTENTION: This drive contains ESD (Electrostatic
!
Discharge) sensitive parts and assemblies. Static control
precautions are required when installing, testing, servicing or
repairing this assembly. Component damage may result if ESD
control procedures are not followed. If you are not familiar with
static control procedures, reference A-B publication 8000-4.5.2,
"Guarding Against Electrostatic Damage" or any other
applicable ESD protection handbook.
• Battery extension cable
• Battery holder
• Screw and nut
• Phillips ®
screwdriver
®
Phillips is a registered trademark of Phillips Screw Company.
Installation Instructions
