Standard XIO Configurable Output 2 [StndXIO Config2]

Linear Number: 458
Default Value: Jog
Access Level: Advanced
Read/Write: Read/Write
This parameter allows the user to select/configure output 2 on the XIO board from a list of 28 available
options. The list is as follows:
Internal
Enum Text
Value
0 Unassigned
1 Reverse
2 Drv Stopping
3 Auto Restart
4 Drv Overload
5 Mtr Overload
6 Thermal Alrm
7 Line Loss
8 CtrlPwr Loss
9 Test Mode
10 At Speed
11 Sync Xfer
12 On Bypass
13 In Trq Limit
14 Drive Accel
15 Drive Decel
16 Jog
17 Remote
18 IsoFan1Ctctr
19 IsoFan2Ctctr
20 Field Enable
21 Field Start
22 Spd Cmd Loss
23 Custom 1
24 Custom 2
25 Custom 3
26 Custom 4
27 Custom 5
Contact Factory for availability
The output is unassigned.
Drive is running in Reverse direction.
Drive is Stopping
Drive is in Auto Restart mode.
Drive is running in an overload condition
Motor is running in an overload condition
Drive has issued an alarm pertaining to its thermal performance
e.g. Loss of converter air flow in air cooled drives or loss of coolant
level in liquid cool drives.
Loss of line input voltage
Loss of 120V AC Control Power
Drive is in Test Mode
Drive is at commanded Speed
Synchronous transfer is enabled
Drive is running on Bypass
Drive is in Torque Limit
Drive is accelerating
Drive is decelerating
Drive is in Jog Mode
Drive is in Remote Mode
Turn Cooling Fan 1 in the Isolation Transformer cabinet
Turn Cooling Fan 2 in the Isolation Transformer cabinet
Field Current regulator is enabled (Synchronous motor only)
Start command to the field regulator (Synchronous motor only)
Speed Command Loss
Custom 1 Output
Custom 2 Output
Custom 3 Output
Custom 4 Output
Custom 5 Output
Parameter Descriptions
Description
