Medium Voltage Support – Technical Services Update
Title:
Product Service Advisory PSA 2012-01-001 Tech Note
(Supersedes PSA 2011-05-001 and PSA 2010-02-001 Tech Notes)
Issued By:
Carlos Siri
Reviewed By:
Manish Pande
Fred Jason
Only personnel who have been trained and understand the PowerFlex 7000 MV Variable
Frequency Drive (VFD) and the Bulletin 1500 product line can work on this equipment.
Appropriate PPE and applicable safety procedures must be followed at all times.
Please refer to the attached sheets.
Please submit any questions you have about this document to:
Rockwell Automation Canada Inc.
135 Dundas Street
Cambridge, Ont.
N1R 5X1
Attn: Medium Voltage Support
Phone:
1.519.740.4790 (Option 1 for MV Technical Support)
Fax:
1.519.740.4756
Email:
mvsupport_technical@ra.rockwell.com
NOTE: The original Customer Letter and subsequent updates mailed/posted refer to Firmware Versions
5.006 through 6.001. In firmware version 6.002 or higher, the Line Filter Capacitor protection method is
upgraded to provide better detection and annunciation, more robust lockout and password reset
functionality, as well as higher immunity to nuisance trips. Please download and install Firmware Version
6.002 or higher per Product Safety Advisory (PSA) 2012-01-001 located on
http://www.rockwellautomation.com/knowledgebase, as ID number 221486.
Page 1 of 17
• Classic Control Users
Date:
March 2, 2012
Date:
March 5, 2012
Tech Note for PSA 2012-01-001
Product Update Number:
PF7000_GEN-95
Products Affected
Active Front End (AFE) Rectifier
PowerFlex 7000 VFD
(7000A, 7000B, 7000L)
•
Classic Control
PF7000_GEN-95
