VIII.7.4 Disconnecting the Line
By clicking on the Tx or Rx Connection areas.
VIII.7.5 Line Status
The Line status is shown on the Tx and Rx Connection areas:
These are the different status messages which can be displayed:
"No physical Line": The communication line is not physically detected. Most
likely the interface is not plugged in. The Display shows "DOWN".
"Connected": The line is connected. An arrow will indicate if it is an incoming
or outgoing call.
The duration of the call also is indicated.
"Disconnected": The line is detected physically but no connection is being
made. Beside the text appear the disconnection codes.
"Calling": In the process of making a connection.
"RING": Receiving a call on the line.
PortaNet User Manual 92 of 156
