Viii.2.3.5 Real Time Monitoring - Prodys PortaNet User Manual

By default this test will attempt to send as much IP traffic as possible. If
you are using this test on a "live" network then it is desirable to limit the test
bandwidth to that which will actually be used. It is also possible to simulate the
same packet rate and bandwidth as that configured for the audio connection
An accurate figure of total bandwidth used (audio data + overhead) can
be obtained from the "Audio Configuaration" screen.
Once the test is finished, it is possible to export the results to an XML file.
VIII.2.3.5 Real Time Monitoring
It is possible to monitor the streaming operation in real time by ticking a
checkbox.
12
Available from version 5.0.0 onwards.
PortaNet User Manual
12
.
75 of 156
