VIII.1.1 Extra Options in the Login Dialog Box
By clicking on the right down corner of the login dialog the screen will show two
more options:
Timeout: If an acknowledgment has not occurred in a specified amount of
time, the timeout ends the waiting loop. In some network conditions could be
necessary to increase the time out in order to get the PortaNet control.
Base Port: When PortaNet ports have been modified, it will be necessary to
change this parameter according to the new port configuration in order to get
to access to the PortaNet web browser.
Changing Portanet Ports: The PortaNet configuration menu allows the
user to configure which ports the unit will use for its TCP/UDP/IP
communications from the web page.
There are two different groups:
Web Server Port: By default, it is TCP port 80. This is the internal web server
port.
PortaNet User Manual
MORE ABOUT THE PORTANET PORTS
50 of 156
