Technical specifications

Audio Interfaces
4 Mic/line inputs:
• XLR connectors.
• Maximum levels:
• Input impedance:
• Mic input sensitivity adjustable from -25 to -65 dBu.
• THD+N < 0.015% (MIC mode), 0.01% (LINE mode). @ 1kHz.
• SNR > 80dB (MIC mode), 95dB (LINE mode).
• Phantom power (48 Volts).
International Sound input:
• XLR connector.
• Maximum level: +20dBu.
• Input impedance: 40Kohm.
• THD+N < 0.01% @ 1kHz.
• SNR < 80dB 95dB .
3 headphone outputs:
• 6.3mm Jack stereo connectors.
• Bandwidth 20Hz-20kHz (1dB).
• Maximum output level: 6dBu (8 mW) over 300 ohm.
• THD+N < 0.01% @ 1kHz.
• SNR < 95 dB.
LINE level outputs:
• XLR male connector (REC output) and 6.3mm Jack stereo connector
(AUX output).
• Bandwidth 20Hz-20kHz (0.3dB).
• Maximum output level: +20dBu.
• THD+N < 0.005% @ 1kHz.
• SNR < 100 dB.
PortaNet User Manual
o LINE levels: +20dBu.
o MIC levels: -46dBu (without compressor).
o MIC levels: -33dBu (with compressor).
o LINE mode = 40Kohm.
o MIC mode = 40Kohm.
145 of 156
