When this option is disabled, this signal will be always available on the
headphone outputs regardless of whether the corresponding input is connected
to the Talkback channel or not.

V.3 Line level balanced audio output: REC

The audio sources for the REC output can be selected from the PortaNet web
browser.
V.3.1 Technical specifications
Bandwidth 20Hz-20kHz (0.3dB).
Maximum audio level: +20dBu.
THD+N < 0.005% @ 1kHz.
SNR < 100 dB.
XLR male connector fitted to the rear panel.
In normal operation, this output carries the audio coming from the
program line (line 1). This audio signal is called CUE.
Output impedance < 50 ohms.
V.3.2 Operation Modes
The REC output supports two different configurations depending on the selected
audio sources in the auxiliary output configuration matrix of the web browser:
PortaNet User Manual 25 of 156
