The fourth MIC/LINE input can use the 'aux' output as
The commentators want to talk to each other.
1. Make a call on line 2 (Call 2 key).
2. Press the TB key of the inputs where the talent's microphones are
connected. The corresponding LED should be on RED.
3. In order for the commentators to be able to hear each other, Talkback
Tx must be selected in the headphone configuration matrix as it can be
seen from the following diagram:
PortaNet User Manual
TB 1
TB 2
+
Headphones 1,2
TalkBack Rx
monitoring output.
Compressor
+
Limiter
MIX 1
Talkback Tx
+
CUE
LINE 2
Decoder
D/A
2
Program Tx
LINE 1
TRANSMISSION
LINE 2
TRANSMISSION
