VVX 201 Phones Hardware

The following figure displays the hardware features on the VVX 201 business media phones. The table
lists each numbered feature shown in this figure.
VVX 201 hardware features
VVX 201 Hardware Feature Descriptions
R ef e re n ce Feature
Number
1 Hookswitch
2 Line keys
3 Speaker
4 Dial pad keys
5 Microphone
6 Volume keys
7 Mute key
User Guide for Polycom VVX201
Feature Description
Cradles the handset and end calls.
Enable you to select a phone line, view calls on a line, or
quickly call a favorite contact.
Provides ringer and speakerphone audio output.
Enable you to enter numbers, letters, and special
characters. You can also use the dial pad keys to select
menu items that have index numbers.
Transmits audio to other phones.
Adjust the volume of the handset, headset, speaker, and
ringer.
Mutes local audio during calls and conferences.
