- Page 1 Progamming Guide Matrix Switchers DTP CrossPoint 84 IPCP Scaling Presentation Matrix Switchers with DTP Extension 68-2349-61 Rev. Ax3 07 14...
-
Page 2: Safety Instructions
Safety Instructions Safety Instructions • English Инструкция по технике безопасности • Русский WARNING: This symbol, , when used on the product, is intended to ПРЕДУПРЕЖДЕНИЕ: Данный символ, , если указан alert the user of the presence of uninsulated dangerous voltage within the на... -
Page 3: Programming Guide
USB driver on your computer. The simplest way to do this is to install and run the Product Configuration Software and then run the Found New Hardware Wizard. DTP Crosspoint 84 IPCP Series Matrix Switchers • Programming Guide... -
Page 4: Default Ip Addresses
The LAN ports give access to either the DTP CrossPoint or the built-in IPCP 350 Pro controller. • The unused ports function as a simple, multiport, unmanaged network switch so that you can connect additional devices to the same network. DTP Crosspoint 84 IPCP Series Matrix Switchers • Programming Guide... -
Page 5: Establishing A Connection
For a telnet session to receive change notices from the switcher, the telnet session must be in verbose mode 1 or 3. See the Verbose Mode SIS commands on page 19. DTP Crosspoint 84 IPCP Series Matrix Switchers • Programming Guide... -
Page 6: Host-To-Switcher Instructions
The switcher initiates the message when the front panel security lockout (executive mode) is toggled on or off from the front panel. “ ” is the executive mode: 0, 1, or 2. DTP Crosspoint 84 IPCP Series Matrix Switchers • Programming Guide... -
Page 7: Switcher Error Responses
The SIS commands are not case sensitive. The ASCII to HEX conversion table below is for use with the command and response table. ASCII to Hex Conversion Table Space • DTP Crosspoint 84 IPCP Series Matrix Switchers • Programming Guide... - Page 8 14). = Voltage Positive or negative voltage and magnitude = Internal temperature Degrees Celsius X2& = Fan speed = Picture adjustments 000 through 127 (064 = default) DTP Crosspoint 84 IPCP Series Matrix Switchers • Programming Guide...
- Page 9 = Scaler output resolution and rate Refresh rate (Hz) 23.98 29.97 59.94 640x480 800x600 1024x768 1280x768 1280x800 1280x1024 1360x768 1366x768 1440x900 1400x1050 1600x900 1680x1050 1600x1200 1920x1200 480p 576p 720p 1080i 1080p 2048x1080 (2k) * Default DTP Crosspoint 84 IPCP Series Matrix Switchers • Programming Guide...
- Page 10 The next two positions ( ) are DTP outputs. Default values: = Rear panel Remote (RS-232) port 2000 2001 2002 = Input 7 and input 8 = Output 3 and output 4 2003 2004 DTP Crosspoint 84 IPCP Series Matrix Switchers • Programming Guide...
- Page 11 = EDID value (resolution and rate) table 1 on the next page. = EDID filename nnnnn.bin. Can include a full path name. File carries 128 or 256 bytes of data. DTP Crosspoint 84 IPCP Series Matrix Switchers • Programming Guide...
- Page 12 User – Assigned EDIDs User assigned 1 User assigned 3 User assigned 5 User assigned 7 User assigned 2 User assigned 4 User assigned 6 User assigned 8 * Default value DTP Crosspoint 84 IPCP Series Matrix Switchers • Programming Guide...
- Page 13 = Detected input audio format = None = 2-channel = 3-channel or bitstream = HDCP authorized device = Off = On (default) = HDCP output = Auto = On (always encrypted) DTP Crosspoint 84 IPCP Series Matrix Switchers • Programming Guide...
-
Page 14: Output Format
= No signal detected = Sync detected X1& = TP and insertion input number = Switch position = DTP = HDBT (output only) = XTP = TP (scaled) and insertion output number DTP Crosspoint 84 IPCP Series Matrix Switchers • Programming Guide... - Page 15 Up to 12 upper- and lower-case alphanumeric characters and _ / and spaces = Lock mode = Mode 0 = Mode 1 = Mode 2 (default) = Scaler preset – DTP Crosspoint 84 IPCP Series Matrix Switchers • Programming Guide...
- Page 16 = Firmware version number to second decimal place ( x.xx ) = Verbose firmware version-description-upload date/time. = Voltage Positive or negative voltage and magnitude = Internal temperature Degrees Celsius X2& = Fan speed DTP Crosspoint 84 IPCP Series Matrix Switchers • Programming Guide...
- Page 17 = TP (scaled) and insertion output number = Picture adjustments 000 through 127 (064 = default) = Position and size ± Horizontal is specified from left, vertical from top) 10240 ( DTP Crosspoint 84 IPCP Series Matrix Switchers • Programming Guide...
- Page 18 Dependent on the input signal and selected scaling. = Overscan percentage = 0% (default) = 2.5% = 5.0% = Aspect ratio fill or follow = fill; = follow = Scaler preset – DTP Crosspoint 84 IPCP Series Matrix Switchers • Programming Guide...
-
Page 19: Test Pattern
= Test pattern = Disable (default) = Color bars = Crop = Grayscale = Alternating pixels = Blue mode = Crosshatch = Crop and pink noise (Ch. 1/2, 48 Hz, 24-bit) DTP Crosspoint 84 IPCP Series Matrix Switchers • Programming Guide... - Page 20 The DTP CrossPoint 84 includes a built-in IPCP Pro control processor that supports the www.extron.com LAN ports and other functionality. See the IPCP Pro Series User Guide at for SIS commands unique to the IPCP control processor. DTP Crosspoint 84 IPCP Series Matrix Switchers • Programming Guide...
- Page 21 EX5& X5&] Read verbose mode X5&] X5*] Configure current port timeout Pti0* Read current port timeout X5*] Configure global IP port timeout X5*] Pti1* Read global IP port timeout X5*] DTP Crosspoint 84 IPCP Series Matrix Switchers • Programming Guide...
-
Page 22: Special Characters
The switcher rejects the following characters: {space (spaces are Ok for names)} + ~ , @ = ‘ [ ] { } < > ’ “ semicolon (;) colon (:) | \ and ?. DTP Crosspoint 84 IPCP Series Matrix Switchers • Programming Guide... -
Page 23: Command And Response Table For Sis Commands
= Group fader soft limit dB value, in 0.1 dB increments. must be within the range for the gain block grouped in X6& = Group type 6= gain 12 = mute DTP Crosspoint 84 IPCP Series Matrix Switchers • DSP SIS Commands... - Page 24 Mic Input Gain Blocks Input Pre- mixer Input Pre-mixer Input Pre-mixer Gain Gain Gain Gain Input 1 Input 3 40000 40100 40002 40102 Input 2 Input 4 40001 40101 40003 40103 DTP Crosspoint 84 IPCP Series Matrix Switchers • DSP SIS Commands...
- Page 25 Expansion Input 5 50104 50204 Virtual Return F Expansion Input 6 50105 50205 Virtual Return G Expansion Input 7 50106 50206 Virtual Return H Expansion Input 8 50107 50207 DTP Crosspoint 84 IPCP Series Matrix Switchers • DSP SIS Commands...
- Page 26 22501 22502 22503 22504 22505 22506 22507 Exp. in 7 22600 22601 22602 22603 22604 22605 22607 22607 Exp. in 8 22700 22701 22702 22703 22704 22705 22706 22707 DTP Crosspoint 84 IPCP Series Matrix Switchers • DSP SIS Commands...
- Page 27 22509 22510 22511 22512 22513 22514 22515 Exp. in 7 22608 22609 22610 22611 22612 22613 22614 22615 Exp. in 8 22708 22709 22710 22711 22712 22713 22714 22715 DTP Crosspoint 84 IPCP Series Matrix Switchers • DSP SIS Commands...
- Page 28 60005 60205 Output 4 Trim Analog DTP Analog Volume Digital DTP Left 60106 60306 60006 60206 Right 60107 60307 60007 60207 * Not used on MA (mono amplifier) model. DTP Crosspoint 84 IPCP Series Matrix Switchers • DSP SIS Commands...
- Page 29 Z40000*1AU DsZ40000*1 Phantom power off Turn phantom power off for object ID *0AU Read phantom power status X6@] : 0 = phantom power off, 1 = phantom power on. DTP Crosspoint 84 IPCP Series Matrix Switchers • DSP SIS Commands...
- Page 30 . In verbose modes 0 and 1, the X6&] response is simplified to View group members is the control or mix-point. In GRPM verbose modes 0 and 1, the response is GrpmO *...* simplified to *...* DTP Crosspoint 84 IPCP Series Matrix Switchers • DSP SIS Commands...
-
