(2) Select a location on the door/window. The large piece of the sensor should be fixed on the
immovable frame of the door/window.
Align the small piece to the large one. Fix the small piece on the movable part of the door/window
frame.
(3) When both parts are fixed, open the door or window to test if the sensor has been correctly
installed. If you have installed the App and sensor correctly you'll receive an alert from your mobile
device.
Mounting Option B - Mounting Screws
(1) Fix the first mounting screw directly onto the door/window frame (A). Place (hang) the
larger piece on to the mounted screw, remove the battery compartment cover to fix the second
mounting screw (B).
(2) Open back cover of the small piece. Use the mounting screws to fix
A
the back cover on the movable part of the door/window frame (C).
Mount the sensor onto the back cover.
C
(3) When it is finished, open the door or window to test if the sensor has
B
been correctly installed. You'll receive an alert from the mobile device if
the App and sensor have been correctly installed.
