Follow these steps for the Bullet Camera:
(a) Lift the rubber flap on the rear of the camera and insert
the mini USB connector end of the USB to RJ45 lead
supplied.
(b) Connect the Ethernet cable to the RJ45 end of the lead.
(c) Proceed with next steps to complete setup.
(3) Using 'Smart-i Protect',
tap in the 'Status'
section and choose to add a
new camera to the
SmartBox. The app will now
search for the camera
connected to the router and
pull in the camera DID.
Status
Gi7-351 GO1-D-038
on Table Room
Siren PowerSwitch
Hallway Book Room
Door Sensor PIR
Back Door Lounge
Remote Key
Status Scenario Event Setting
Select Device
Camera
Siren
Remote Key
Door Sensor
Motion Sensor
Power Switch
Status Scenario Event Setting
19
