The diagram below shows the suggested location(s) for SmartHome Security System. Use this
as a guide for your installation. The system is extendable and expandable with additional
Power Control
Remote Control
Battery CR2032
SmartBox
Adaptor DC 12V/1A
12
Indoor/Outdoor
Camera
Adaptor DC 5V/1.5A
PIR Sensor
Battery AA 1.5V x 3
