(3A) Auto Pairing Method
Remove the insulating
plastic tab to start the
pairing signal.
(4) Enter 'Device Name' and 'Location', tap 'Save' to complete the pairing process. The newly
paired sensor will now display in the App's 'Status' section.
Verifying the Setup
After pairing is complete, separate the two parts of the sensor and the alert indicator should
appear next to the door/window sensor section on the status page of the App.
26
Select Device
Status
Gi7-351 GO1-D-038
Camera
on Table Room
Siren
Siren PowerSwitch
Remote Key
Hallway Book Room
Door Sensor
Door Sensor PIR
Back Door Lounge
Motion Sensor
Remote Key
Power Switch
Status Scenario Event Setting
Status Scenario
Step 1 of 3
Please tap "Pair" to begin pairing
process
Event Setting Status Scenario Event Setting
(3B) Manual Pairing Method
Remove the battery cover and
battery and then replace both.
