2. Setup the Cameras

NOTE: You can ONLY setup camera(s) compatible with the system. If you have previously
purchased and installed compatible camera(s), you will only need to complete steps (3) and
(4) for your existing camera to work with the new system.
For wireless connection/operation please follow Step (6).
(1) First connect the camera to the Wi-Fi router via the Ethernet cable supplied.
(2) Power on the camera via the power adaptor supplied and wait until for both RED (power
indicator) /GREEN (linkage indicator) indicators become steady on - DO NOT begin the App setup
process until both LEDs are steady on the camera.
18
NOTE: Follow the same
Setup procedure for the
Pan Tilt Camera
