3. How to Install
3.4. Connection Examples
3.4.1. Start/Stop
Terminal 18 = Par. 5-10 [8]
Terminal 27 = Par. 5-12 [0]
3
fault
Terminal 37 = Safe stop (where available!)
3.4.2. Pulse Start/Stop
Terminal 18 = Par. 5-10 [9]
Terminal 27= Par. 5-12 [6]
Terminal 37 = Safe stop (where available!)
36
Start
No operation
coast inverse
)
Latched start
Stop inverse
MG.33.A9.22 - VLT is a registered Danfoss trademark
®
VLT
AutomationDrive FC 300 Instruction
(De-
Manual
