3.3. Electrical Installation

Aluminum Conductors
Terminals can accept aluminum conductors, but the conductor surface must be clean, and the
oxidation must be removed and sealed by neutral acid-free Vaseline grease before the conductor
is connected.
Furthermore, the terminal screw must be retightened after two days due to the softness of the
aluminum. It is crucial to keep the connection a gas-tight joint, otherwise the aluminum surface
will oxidize again.
Tightening-up Torque
AFD size
A1
A2
A3
A5
B1
B2
C1
C2
D1, D3
D2, D4
E1, E2
NOTE
Cables General
All cabling must comply with national and local regulations on cable cross-sections
and ambient temperature. Copper (140°-167° F [60°/75° C]) conductors are rec-
ommended.
200-240 V 380-500 V 525-690 V
0.33-2 hp 0.5-2 hp
[0.25-1.5 kW] [0.37-1.5 kW]
0.33-3 hp 0.5-5 hp 1-5 hp [0.75-4
[0.25-2.2 kW] [0.37-4 kW] kW]
4-5 hp [3-3.7 7.5-10 hp 7.5-10
kW] [5.5-7.5 kW] [5.5-7.5 kW]
4-5 hp [3-3.7 7.5-10 hp 1-10
kW] [5.5-7.5 kW] [0.75-7.5 kW]
7.5-10 hp 15-20 hp
[5.5-7.5 kW] [11-15 kW]
11 kW 25-30 hp
[18.5-22 kW]
20-30 hp 40-60 hp
[15-22 kW] [30-45 kW]
40-50 hp 75-100 hp
[30-37 kW] [55-75 kW]
- 125-150 hp 150-200 hp
[90-110 kW] [110-132 kW]
- 200-300 hp 250-450 hp
[132-200 kW] [160-315 kW]
- 350-550 hp 500-750 hp
[250-400 kW] [355-560 kW]
MG.33.A9.22 - VLT is a registered Danfoss trademark
Cable for: Tightening torque
- Line, brake resistor, load 0.5-0.6 Nm
sharing, motor cables
hp
hp
- Line, brake resistor, load 1.8 Nm
sharing, motor cables
Relay 0.5-0.6 Nm
Ground 2-3 Nm
- Line, brake resistor, load 4.5 Nm
sharing cables
Motor cables 4.5 Nm
Relay 0.5-0.6 Nm
Ground 2-3 Nm
- Line, brake resistor, load 10 Nm
sharing cables
Motor cables 10 Nm
Relay 0.5-0.6 Nm
Ground 2-3 Nm
- Line, brake resistor, load 14 Nm
sharing cables
Motor cables 10 Nm
Relay 0.5-0.6 Nm
Ground 2-3 Nm
Line, motor cables 19 Nm
Load sharing, brake cables 9.5 Nm
Relay 0.5-0.6 Nm
Ground 19 Nm
Line, motor cables 19 Nm
Load sharing, brake cables 9.5 Nm
Relay 0.5-0.6 Nm
Ground 19 Nm
Line, motor cables 19 Nm
Load sharing, brake cables 9.5 Nm
Relay 0.5-0.6 Nm
Ground 19 Nm
