VLT AutomationDrive FC 300 Instruction
Manual
No. Description
61 Tracking Error
62 Output Frequency at Maximum Limit
63 Mechanical Brake Low
64 Voltage Limit
65 Control Board Overtemperature
66 Heatsink Temperature Low
67 Option Configuration Has Changed
68 Safe Stop
70 Illegal FC configuration
71 PTC 1 Safe Stop
72 Dangerous Failure
80 Drive Initialized to Default Value
90 Encoder Loss
91 Analog input 54 wrong settings
100-
See Instruction Manual for MCO 305
199
250 New spare part
251 New Type Code
6.2: Alarm/Warning code list
(X) Dependent on parameter
1) Cannot be auto-reset via Par 14-20
A trip is the action taken when an alarm has
occurred. The trip will coast the motor and can
be reset by pressing the reset button or make
a reset by a digital input (Par. 5-1* [1]). The
event that causes an alarm cannot damage
the drive or result in dangerous conditions. A
trip lock is the action taken when an alarm oc-
curs that may cause damage to the drive or
Warning
(X)
X
X
X
X
(X)
X
(X)
MG.33.A9.22 - VLT is a registered Danfoss trademark
6. Troubleshooting
Alarm/Trip Alarm/Trip Lock
(X)
(X)
X X
X
1)
(X)
X
1)
X
1)
X
X
(X)
X
X
X X
its connected parts. A trip lock situation can
only be reset by a power cycling.
LED indication
Warning yellow
Alarm flashing red
Trip-locked yellow and red
Parameter
Reference
4-30
2-20
5-19
5-19
5-19
17-61
S202
14-23
89
6
