Danfoss VLT AutomationDrive FC 300 Instruction Manual page 31

®
VLT AutomationDrive FC 300 Instruction
Manual
UL Compliance
Alternate Fuses 200-240 V drives 1/3 hp
to 30 hp (0.25 kW - 22 kW)
FC 300
kW
K25-K37
K55-1K1
1K5
2K2
3K0
3K7
5K5
7K5
11K
15K-18K5
FC 300
kW
K25-K37
K55-1K1
1K5
2K2
3K0
3K7
5K5
7K5
11K
15K-18K5
Alternate Fuses 200-240 V drives 30 hp
to 60 hp (22 kW - 45 kW)
FC 300
kW
22K
30K
37K
Bussmann Bussmann
Type RK1 Type J
KTN-R05 JKS-05
KTN-R10 JKS-10
KTN-R15 JKS-15
KTN-R20 JKS-20
KTN-R25 JKS-25
KTN-R30 JKS-30
KTN-R50 KS-50
KTN-R60 JKS-60
KTN-R80 JKS-80
KTN-R125 JKS-150
SIBA
Type RK1
5017906-005
5017906-010
5017906-016
5017906-020
5017906-025
5012406-032
5014006-050
5014006-063
5014006-080
2028220-125
Bussmann
Type JFHR2 Type RK1
FWX-150 2028220-150
FWX-200 2028220-200
FWX-250 2028220-250
KTS fuses from Bussmann may substitute for KTN in 240 V adjustable frequency drives.
FWH fuses from Bussmann may substitute for FWX in 240 V adjustable frequency drives.
JJS fuses from Bussmann may substitute for JJN in 240 V adjustable frequency drives.
KLSR fuses from LITTEL FUSE may substitute for KLNR in 240 V adjustable frequency
drives.
L50S fuses from LITTEL FUSE may substitute for L25S fuses in 240 V adjustable fre-
quency drives.
A6KR fuses from FERRAZ SHAWMUT may substitute for A2KR in 240 V adjustable fre-
quency drives.
A50X fuses from FERRAZ SHAWMUT may substitute for A25X in 240 V adjustable fre-
quency drives.
MG.33.A9.22 - VLT is a registered Danfoss trademark
Bussmann Bussmann Bussmann
Type T Type CC Type CC
JJN-06 FNQ-R-5 KTK-R-5
JJN-10 FNQ-R-10 KTK-R-10
JJN-15 FNQ-R-15 KTK-R-15
JJN-20 FNQ-R-20 KTK-R-20
JJN-25 FNQ-R-25 KTK-R-25
JJN-30 FNQ-R-30 KTK-R-30
JJN-50 -
JJN-60 -
JJN-80 -
JJN-125 -
Ferraz-
Littel fuse
Shawmut
Type RK1 Type CC
KLN-R05 ATM-R05
KLN-R10 ATM-R10
KLN-R15 ATM-R15
KLN-R20 ATM-R20
KLN-R25 ATM-R25
KLN-R30 ATM-R30
KLN-R50 -
KLN-R60 -
KLN-R80 -
KLN-R125 -
SIBA Littel fuse
JFHR2
L25S-150
L25S-200
L25S-250
3. How to Install
Bussmann
Type CC
LP-CC-5
LP-CC-10
LP-CC-15
LP-CC-20
LP-CC-25
LP-CC-30
- -
- -
- -
- -
Ferraz-
Shawmut
Type RK1
A2K-05R
A2K-10R
A2K-15R
A2K-20R
A2K-25R
A2K-30R
A2K-50R
A2K-60R
A2K-80R
A2K-125R
Ferraz-
Shawmut
JFHR2
A25X-150
A25X-200
A25X-250
29
3
