General-purpose I/Os (GPIO)
Function Description
Parameters
Return values
Notes
12.3

GPIO Firmware driver defines

12.3.1

GPIO

GPIO
GPIO_Alternate_function_selection_define

#define: GPIO_AF_0 ((uint8_t)0x00)
242/584
Writes data to the specified GPIO data port.

GPIOx : where x can be (A, B, C, D, E or F) to select the
GPIO peripheral.

GPIO_PinSource : specifies the pin for the Alternate
function. This parameter can be GPIO_PinSourcex where x
can be (0..15).

GPIO_AF : selects the pin to be used as Alternate function.
This parameter can be one of the following value:

GPIO_AF_0 :
JTMS-SWDAT, MCO, NJTRST, TRACED, TRACECK.

GPIO_AF_1 :

GPIO_AF_2 :
TIM8, TIM15.

GPIO_AF_3 :

GPIO_AF_4 :

GPIO_AF_5 :
USART4, USART5

GPIO_AF_6 :
TIM8

GPIO_AF_7 :
COMP5_OUT, COMP6_OUT, USART1, USART2,
USART3.

GPIO_AF_8 :
COMP3_OUT, COMP4_OUT, COMP5_OUT,
COMP6_OUT.

GPIO_AF_9 :

GPIO_AF_10 :
TIM4, TIM8, TIM17.

GPIO_AF_11 :

GPIO_AF_12 :

GPIO_AF_14 :

GPIO_AF_15 :

None.

The pin should already been configured in Alternate Function
mode(AF) using GPIO_InitStruct->GPIO_Mode =
GPIO_Mode_AF

Refer to the Alternate function mapping table in the device
datasheet for the detailed mapping of the system and
peripherals alternate function I/O pins.
