Real-time clock (RTC)
19.2.28.2 RTC_GetStoreOperation
Function Name
Function Description
Parameters
Return values
Notes
19.2.29

Output pin configuration functions

19.2.29.1 RTC_OutputConfig
Function Name
Function Description
Parameters
Return values
Notes
382/584
uint32_t RTC_GetStoreOperation ( void )
Returns the RTC Day Light Saving stored operation.

None.

RTC Day Light Saving stored operation.

RTC_StoreOperation_Reset

RTC_StoreOperation_Set

None.
void RTC_OutputConfig ( uint32_t RTC_Output, uint32_t
RTC_OutputPolarity)
Configures the RTC output source (AFO_ALARM).

RTC_Output : Specifies which signal will be routed to the
RTC output. This parameter can be one of the following
values:

RTC_Output_Disable :

RTC_Output_AlarmA :
output

RTC_Output_AlarmB :
output

RTC_Output_WakeUp :
output

RTC_OutputPolarity : Specifies the polarity of the output
signal. This parameter can be one of the following:

RTC_OutputPolarity_High :
when the ALRAF/ALRBF/WUTF is high (depending on
OSEL)

RTC_OutputPolarity_Low :
the ALRAF/ALRBF/WUTF is high (depending on OSEL)

None.

None.
DocID023800 Rev 1
No output selected
signal of AlarmA mapped to
signal of AlarmB mapped to
signal of WakeUp mapped to
The output pin is high
The output pin is low when
UM1581
