2.22 - SERIAL BRIDGE ART. 20090334

The Serial Bridge module makes it possible to communicate with the SimpleHome home automation BUS and the SimpleSafe anti-intrusion system.
It can be used as follows:
• weekly schedule programmer: sends commands to outputs, zones, scenarios and thermostats within the system.
• link in/out management: links an alarm control panel event (area status or input status) to an event for transmission over the home
automation BUS (modules, zones, scenarios, etc...).
• rule management: programs 3-element rules with AND/OR functions between inputs, outputs or security/home automation timer in
order to generate an event.
• scenario management: can program scenarios which include procedures for transmission to the SimpleSafe security system and/or the
SimpleHome home automation system.
User setup and management must take place via the WEB interface.
The Serial Bridge is a Web Server device which, by means of a PC browser, tablet, smartphone, etc... is able to do the following without the installation
of any additional programs:
Display/Control
From the Serial Bridge it is possible to confi gure:
46
Technical characteristics
8 areas of a compatible alarm control unit.
48 lights over BUS.
24 sockets over BUS.
24 timed outputs or shutter.
24 analogue inputs, which may be:
• 20046707 modules confi gured as thermostat with temperature sensor connected.
• thermostats and temperature sensors on the BUS.
Display the status of the fi rst 80 wired inputs of a compatible control unit.
the status of the fi rst 48 radio inputs of a compatible control unit.
8 load modules by consumption/production.
Control the 16 scenarios set on the device.
up to 32 timers.
up to 32 commands sent over the link between the alarm control unit and the SimpleSafe BUS.
up to 32 rules with 3 elements each.
up to 32 scenario commands with 20 elements each.
