3.6.3 - CONFIGURING ONE MODULE SCREENS

The ONE control device has 3 screens that can be programmed with 3 different functions:
• Automation management
• Scenario management (max. 1 screen per device)
• Climate management (max. 1 screen per device)
3.6.3.1 - AUTOMATION MANAGEMENT
AUTOMATIONS/SCENARIO/CLIMATE:
this menu can be used to customise the colour of the screen indicator (this appears in the top right-hand
SCREEN 1 INDICATOR:
corner of the device), assigning one colour to the screen when it is active and another when the screen is inactive.
this drop-down menu can be used to specify what is to be shown on the display for each sector (max. 3): buttons (1,
COMMANDS:
2 or 3) or arrows.
COMMAND CONFIGURATION:
INPUT DESCRIPTION
Field used to enter a short description of the function or the module managed by the button/arrow.
MESSAGE ADDRESSEE
the module + output function is used to control one or more module outputs. When this option is selected,
MODULE + OUTPUT:
you must enter the number of the module and output(s) you wish to control.
the function enables control of several outputs on different modules. This setting is used to send a command which
ZONE:
switches off all the lights in an apartment or lowers all the shutters, etc... To do this, the outputs must be assigned to the same
zone or group on the output settings screen.
For example, if you want to control all the lights, one zone (for example ZONE 5) must be assigned to all the outputs connected
to the lights, and then an input set as "Zone" in the message addressee fi eld, entering zone number 5.
100
select the Automations function in this menu.
this menu changes depending on the number of buttons or arrows selected in the previous step.
