2.9 - ART. 20046605 - SIMPLEHOME MODULE WITH 9 OPTICALLY COUPLED INPUTS
AND 8 X 6A RELAY OUTPUTS ON DIN RAIL (9I8O6A)
Module on bus has 8 inputs + 1 scenario input, as well as 8 relay outputs with NO contact with capable of controlling resistive electrical loads up
to 6A. The outputs on the device are not suitable for controlling particularly heavy loads or halogen and fl uorescent lamps. When controlling these
loads, a support contactor must be used at each output.
Power supply voltage
Absorption
Inputs
Outputs
Max. input cable length
Protection
Indications
Lack and restoring of
power supply
Terminals
Positioning
Applicable standards
Approvals
Operating temperature
Storage temperature
Relative air humidity
Weight
Dimensions
Technical characteristics
24 Vdc ± 5%
min. 8mA, max. 167 mA
8+1, optically coupled digital type
8 relay 230 Vac, resistive 6A (cos ϕ = 1)
25 m
against reverse polarity
1 bus status indicator LED: when fl ashing, indicates data transmission via bus, when lit steadily
indicates lack of power supply negative or incorrect device connection
9 input status indicator LEDs
8 output status indicator LEDs
Output status memory
removable for BUS connection
On DIN rail or in junction boxes
electromagnetic compatibility: EN 50081-1 (interference emission)
and EN50082-2 (resistance to interference)
CE
0° to 50°C
-10° to +70°C
5 to 95% with no condensation
180 g (not including packaging)
71x90x58 mm (4 DIN modules)
