2.3 - ART. 20046502 - SIMPLEHOME MODULE WITH 5 DIGITAL INPUTS
AND 4 TRANSISTOR OUTPUTS, FLUSH-MOUNTED (5I4O)
The module with 5 digital inputs / 4 transistor outputs allows the connection of up to 5 contacts (buttons, switches, diverters, inverters,
general sensors...) for controlling the outputs on the SimpleHome system module. and 4 transistor outputs for direct connection of
the 24 V indicator LEDs in cc or a relay with a maximum activation current of 50 mA.
The compact interface can be installed in traditional "3-module" boxes (concealed behind the electromechanical modules in the civil
series) or in junction boxes.
The module with 5 digital inputs is powered directly by the bus.
Power supply voltage
Absorption
Inputs
Outputs
Max. input cable length
Protection
Indications
Lack and restoring of
power supply
Terminals
Positioning
Applicable standards
Approvals
Operating temperature
Storage temperature
Relative air humidity
Weight
Dimensions
12
Technical characteristics
24 Vdc ± 5%
min. 5 mA, max. 22 mA
4+1, optically coupled digital type
4 transistor 24 Vdc 50 mA max. per output
25 m
against reverse polarity
1 indicator LED: when fl ashing, indicates data transmission via bus, when lit steadily indicates lack of
power supply negative or incorrect device connection
Output status memory
removable for BUS connection
in fl ush-mounted boxes
electromagnetic compatibility: EN 50081-1 (interference emission) and EN50082-2 (resistance to
interference)
CE
0° to 50°C
-10° to +70°C
5 to 95% with no condensation
24 g (not including packaging)
41x29x9 mm
