EN
TECHNICAL
MANUAL
Technical manual for the SimpleHome system
www.comelitgroup.com

Advertisement

Table of Contents
loading

Summary of Contents for Comelit simplehome

  • Page 1 TECHNICAL MANUAL Technical manual for the SimpleHome system www.comelitgroup.com...
  • Page 2 • Install the equipment by carefully following the instructions given by the manufacturer and in compliance with the standards in force. • All the equipment must only be used for the purpose it was designed for. Comelit Group S.p.A. does not assume responsibility for improper use of the apparatus, for modifi cations made by third parties for any reason or purpose, or for the use of non-original accessories and materials.

  • Page 3: Table Of Contents

    TREE MENU SCREEN AND MODULE PROGRAMMING ART. 20046501 - SIMPLEHOME MODULE WITH 5 INPUTS, FLUSH-MOUNTED (5I) MODULE PROGRAMMING ART. 20046502 - SIMPLEHOME MODULE WITH 5 DIGITAL 3.5.1 ADDING A PLANUX MANAGER / MINITOUCH INPUTS AND 4 TRANSISTOR OUTPUTS, MODULE FLUSH-MOUNTED (5I4O) 3.5.2...

  • Page 4: Introduction P

    1 - INTRODUCTION Besides a short introduction to the philosophy behind SimpleHome by Comelit, this manual also provides a detailed description of the range of home automation products currently available and the corresponding programming/confi guration software. 1.1 - SIMPLEHOME: DISTRIBUTED INTELLIGENCE AND PROPRIETARY PROTOCOL...
  • Page 5 In fact, each SimpleHome device is powered directly by the 3-wire bus and therefore once the number and type have been identifi ed, it will be possible to look up the nominal absorption of the system using this table:...

  • Page 6: Communication Type

    2 or 200 modules. A SimpleHome system can be perceived as a set of several subsystems, each one capable of controlling up to 255 devices and a bus section up to 2 km long;...

  • Page 7: Digital And Analogue Input

    1.6 - DIGITAL AND ANALOGUE INPUT OPERATING PRINCIPLE To fully understand the system, it is vital to grasp what happens when a button is pressed or released (digital input closed or opened); every time there is a change to an input, the corresponding module sends a message over the bus which, as mentioned previously, can be destined for various recipients: - a module and one or more of the outputs on it;...

  • Page 8: Supervisors

    1.8 – SUPERVISORS SimpleHome modules possess their own intelligence and therefore do not need a control unit; however, if the user needs a graphics interface to view the status of his/her on system and adjust its operation as necessary, various supervision instruments can be used.

  • Page 9: Devices

    2 - DEVICES The devices used to construct the SimpleHome system are described below. 2.1 - ART. 20022101 - SWITCHING POWER SUPPLY UNIT FOR SIMPLEHOME SYSTEM 24 Vdc 2A ON DIN RAIL Supplies power at 24 Vdc with current up to 2A via the BUS: several power supply units can be connected in parallel and distributed at various points of the system, to supply the energy required for correct operation of the connected devices.
  • Page 10 CONNECTION TERMINALS Terminal Function Bus power supply negative + 24 Vdc bus power supply NC contact FAIL (power supply failure indication) Earth Power supply phase (230 Vac) Power supply neutral (230 Vac) Earth terminal connection may cause disturbance on the communication Specifi cations are subject to change without notice.

  • Page 11: Art. 20046501 - Simplehome Module With 5 Inputs, Flush-Mounted (5I)

    The module with 5 digital inputs allows the connection of up to 5 contacts (buttons, switches, diverters, inverters, general sensors...) for controlling the outputs on the SimpleHome system module. The compact interface can be installed in traditional "3-module" boxes (concealed behind the electromechanical modules in the civil series) or in junction boxes. The module with 5 digital inputs is powered directly by the bus.

  • Page 12: Art. 20046502 - Simplehome Module With 5 Digital

    The module with 5 digital inputs / 4 transistor outputs allows the connection of up to 5 contacts (buttons, switches, diverters, inverters, general sensors...) for controlling the outputs on the SimpleHome system module. and 4 transistor outputs for direct connection of the 24 V indicator LEDs in cc or a relay with a maximum activation current of 50 mA.
  • Page 13 (+) Input 1 blue (-) Multiple command (scenario) +24 Vdc support (inputs) N.B. The module must be programmed via the BUS line, using the SimpleHome/RS232 interface (20022611) and the SimpleProg programming software. Specifi cations are subject to change without notice.

  • Page 14: Art. 20046912 - Simplehome Flush-Mounted

    2.4 - ART. 20046912 – SIMPLEHOME FLUSH-MOUNTED INTERFACE MODULE WITH 2 RELAYS (RL2) Interface with two 6A resistive relays (cosϕ=1) for connection to bus modules with open-collector outputs, for example those controlling a rolling shutter motor. The outputs on the device are not suitable for controlling particularly heavy loads or halogen and fl uorescent lamps. When controlling these load types, a support relay must be used at each output.
  • Page 15 Connection example for module with 5 inputs / 4 transistor outputs used to control an automated rolling shutter green (bus) red (+) blue (-) Specifi cations are subject to change without notice.

  • Page 16: Art. 20046707 - Simplehome Flush-Mounted

    BUS power supply +24 Vdc BUS data line Input 1 (0-10 V) green (bus) red (+) Input 2 (0-10 V) blue (-) N.B. The module must be programmed via the BUS line, using the SimpleHome/RS232 interface (20022611) and the SimpleProg programming software.
  • Page 17 Temperature sensor 20046708 connection example TEMPERATURE SENSOR 20046708 DEVICE TEMPERATURE MEASURING SENSOR green (bus) red (+) blue (-) Specifi cations are subject to change without notice.

  • Page 18: Art. 20046708 - Simplehome Temperature

    2.6 - ART. 20046708 - SIMPLEHOME TEMPERATURE SENSOR MODULE WITH 0-10 V OUTPUT, FLUSH-MOUNTED (TEMP) Temperature sensor with standard 0-10 V output for connection to the fl ush-mounted module with 2 x 0-10 V analogue inputs (20046707). The dimensions are designed so that the product can be fi tted in the most common civil series, for example inside a button blank.

  • Page 19: Art. 20046709 - Simplehome Flush-Mounted Lcd Thermostat Module

    2.7 - ART. 20046709 - SIMPLEHOME FLUSH-MOUNTED LCD THERMOSTAT MODULE Room thermostat with LCD display, offering the option of connection to the SimpleHome system for supervisor control. It allows temperature adjustment between 5 and 30°C by means of a knob, and the temperature can be viewed via the LCD display. The device sends a data package containing the measured temperature value over the bus at regular intervals and, immediately afterwards, measures the room temperature.
  • Page 20 FRONT PANEL INDICATIONS AND COMMANDS Local relay status (if activated, steady red) or transit status of signals over bus Time (fl ashing, red or green). Display temperature measured within the room. Set operating mode: DIVERTER - SUMMER SLIDER - WINTER - OFF Set room temperature KNOB...
  • Page 21 Depending on the civil series installed, modify the universal subframe supplied in accordance with the following instructions: Subframe 1 For entrance panels: BTICINO Living International BTICINO Light BTICINO Light Tech (SILVER LIGHT TECH fi nish front panel and knob optional) Note for the installer: with Living International, Light and Light Tech BTICINO series entrance panels, if the relevant BTICINO subframes are already on the fl ush-mounted box, the thermostat can be fi tted directly to them.
  • Page 22 The module also offers the following functions: Remote valve: in addition to the relay on board the thermostat, an external relay on one of the modules on the Din bar of the home automation bus can be used to control a remote electrovalve. To enable this function, check the "Remote valve control" box (for summer or winter) in the confi guration program and enter the number of the module on which the relay is located.

  • Page 23: Art. 20046604 - Simplehome Module

    2.8 - ART. 20046604 - SIMPLEHOME MODULE WITH 5 OPTICALLY COUPLED INPUTS AND 4 X 16A RELAY OUTPUTS ON DIN RAIL (5I4O16A) Module on bus has 4 inputs + 1 scenario input, as well as 4 relay outputs with switching contact with independent common capable of controlling resistive electrical loads up to 16A.
  • Page 24 Output 4 – NO contact Output 4 – Common Output 4 – NC contact N.B. The module must be programmed via the BUS line, using the SimpleHome/RS232 interface (20022611) and the SimpleProg programming software. Specifi cations are subject to change without notice.

  • Page 25: Outputs On Din Rail (9I8O6A)

    2.9 - ART. 20046605 - SIMPLEHOME MODULE WITH 9 OPTICALLY COUPLED INPUTS AND 8 X 6A RELAY OUTPUTS ON DIN RAIL (9I8O6A) Module on bus has 8 inputs + 1 scenario input, as well as 8 relay outputs with NO contact with capable of controlling resistive electrical loads up to 6A.
  • Page 26 Output 8 – NO contact Output common 5-6-7-8 +24 Vdc support Multiple command (scenario) N.B. The module must be programmed via the BUS line, using the SimpleHome/RS232 interface (20022611) and the SimpleProg programming software. Specifi cations are subject to change without notice.

  • Page 27: Outputs On Din Rail (9I8O16A)

    2.10 - ART. 20046606 - SIMPLEHOME MODULE WITH 9 OPTICALLY COUPLED INPUTS AND 8 X 16A RELAY OUTPUTS ON DIN RAIL (9I8O16A) Module on bus has 8 inputs + 1 scenario input, as well as 8 relay outputs with switching contact with independent common capable of controlling resistive electrical loads up to 16A.
  • Page 28 Output 8 – Common Input 2 Output 4 – Common Output 8 – NC contact N.B. The module must be programmed via the BUS line, using the SimpleHome/RS232 interface (20022611) and the SimpleProg programming software. Specifi cations are subject to change without notice.

  • Page 29: Art. 20046810 - Simplehome Module With

    AND 2 ANALOGUE OUTPUTS ON DIN RAIL (2I2O) Interface on DIN rail for SimpleHome system, with two inputs and two 0-10 V analogue outputs. Allows interfacing between the automation system and analogue inputs, such as light sensors or voltage/current transformers, as well as the management of electronic adjustment devices such as lighting ballasts or dimmers.
  • Page 30 Output 2 (0-10 V) DIMMER OR BALLAST Output 2 support negative ELECTRONIC N.B. The module must be programmed via the BUS line, using the SimpleHome/RS232 interface (20022611) and the SimpleProg programming software. Specifi cations are subject to change without notice.

  • Page 31: Art. 20046821 - Load Management Module

    The SimpleHome module 20046821 can be used to measure the power absorbed or produced over a single-phase system with a voltage of 230 Vac. By installing this module in the SimpleHome system and connecting it to the BUS, it will be possible to view the power value measured by the module on one of the supervisors (e.g.
  • Page 32 Accessories included CT current transformer Weight 70 g, not including CT and packaging Dimensions 35x90x58 mm (3 DIN modules) CONNECTION TERMINALS BUS SimpleHome Terminal Function BUS power supply negative BUS power supply +24 Vdc BUS data line V- IT Input for non-polarised toroid connection...

  • Page 33: Art. 20022611 - Simplehome/Rs232

    2.13 - ART. 20022611 - SIMPLEHOME/RS232 INTERFACE Serial interface for SimpleHome system programming; to use it, plug the 9-pin connector into the serial port (RS232) on the PC or another programming device and connect the 3 bus wires to the numbered terminal, observing the correspondence indicated in the table below.

  • Page 34: Art. 20004100 - Temperature Sensor

    2.14 - ART. 20004100 - TEMPERATURE SENSOR Sensor operation Once connected to the SimpleHome system, the temperature sensor is controlled by the supervisor. The device regularly transmits a data package (containing the recorded temperature value) via the bus. The temperature sensor, depending on the setpoint, is updated and transmits a remote output activation or deactivation command via the bus.
  • Page 35 Sensor mounting Fastening Unfastening...

  • Page 36: Outputs (3I3O)

    2.15 - ART. 20004601 – MODULE WITH 3 INPUTS AND 3 OUTPUTS (3I3O) SimpleHome module Art. 20004601 has 3 inputs (voltage-free contacts, E.G. buttons, sensors, etc...) and 3 outputs, 2 of which require connection of an external relay (E.G. Art. 20004603) while the other controls an on-board 16A relay (this can be programmed as a NO. NC.

  • Page 37: Art. 20004602 - Module With 1 Output

    2.16 - ART. 20004602 – MODULE WITH 1 OUTPUT SimpleHome module Art. 20004602 has 1 output, which controls an on-board 16A relay (can be programmed as a NO. NC. output using suitable programming software). Module Art. 20004602 allows fl ush mounting in residential series boxes or on DIN rails.

  • Page 38: Art. 20004603 - Module With 2 Relays

    2.17 - ART. 20004603 – MODULE WITH 2 RELAYS SimpleHome module Art. 20004603 has two 10A relay outputs which are activated from +24 Vdc transistor outputs found, for example, on modules 20004601 or 20046502. Module Art. 20004603 allows fl ush mounting in residential series boxes or on DIN rails.

  • Page 39: Art. 20004604 - Module With Pulse Meter

    2.18 - ART. 20004604 – MODULE WITH PULSE METER SimpleHome module Art. 20004604 has 3 pulse-type inputs to which meters with a pulse output can be connected. The data gathered by module Art. 20004604 is processed by compatible supervisors in the SimpleHome series, to provide statistical data for the measured values.

  • Page 40: Art. 20003001 - Minitouch Timer-Thermostat

    2.19 - ART. 20003001 – MINITOUCH TIMER-THERMOSTAT 3.5" MiniTouch with timer-thermostat function. To be connected to the SimpleHome bus. Allows control, monitoring and scheduling of all climate zones within the system (sensors, thermostats, Minitouch) Technical characteristics Colour Black Smart Light...
  • Page 41 Minitouch timer-thermostat mounting...

  • Page 42: Planux Manager Monitor Art

    3.5” touch screen colour monitor. Full-duplex video door entry function, audio adjustment, customisable ringtones. To be connected to the SimpleHome BUS for automation system management, e.g. lights, loads, shutters, climate, scenarios or irrigation, and to the SimpleSafe System for anti-intrusion system viewing and control.
  • Page 43 Planux Manager mounting 14,5 cm ALTO HAUT OBEN...

  • Page 44: Minitouch Monitor Art. 20034607

    2.21 - MINITOUCH MONITOR ART. 20034607 3.5" MiniTouch with supervisor function. To be connected to the SimpleHome BUS for automation system management, controlling lights, loads, shutters, climate, scenarios or irrigation, and to the SimpleSafe System for anti-intrusion system viewing and control.
  • Page 45 Minitouch mounting...

  • Page 46: Serial Bridge Art. 20090334

    2.22 - SERIAL BRIDGE ART. 20090334 The Serial Bridge module makes it possible to communicate with the SimpleHome home automation BUS and the SimpleSafe anti-intrusion system. It can be used as follows: • weekly schedule programmer: sends commands to outputs, zones, scenarios and thermostats within the system.
  • Page 47 POWER / STATUS 1 Connection terminals: - + : 12/24 Vdc power supply from home automation BUS or alarm control unit. D: Simplehome BUS data terminal. NC - NO - C: Voltage-free relay contacts. I2: Status input 2. K: Common status input.

  • Page 48: Dali/Dmx Module Art. 20004600

    2.23 - DALI/DMX MODULE ART. 20004600 The DALI/DMX module art. 20004600 converts Simplehome system commands to commands on the DALI or DMX communication BUS. Commands sent to DMX power supply units can switch the connected light source on / off, dim it or adjust its colour (if using RGB lights).
  • Page 49 Technical characteristics Power supply voltage 24 Vdc ± 5% Absorption MIN. 5 mA / MAX. 40 mA Indications 1 bus status LED: when fl ashing, indicates data transmission via bus. Terminals Removable Positioning On DIN rail or in junction boxes Approvals Operating temperature 0°...

  • Page 50: Simpleprog, The Simplehome System Configuration Software

    3 - SIMPLEPROG, THE SIMPLEHOME SYSTEM CONFIGURATION SOFTWARE As mentioned several times in this manual, the entire SIMPLEHOME system must be confi gured using a PC and the SIMPLEPROG software in order to work. Below is a short guide to using the software, bearing in mind that in each programming phase, SIMPLEPROG always displays the necessary information and a short description of the available functions on the screen.

  • Page 51: The Main Screen

    Once the program has started, you will see the following main screen: AVAILABLE COMMANDS PROGRAM MODULES: once confi guration has taken place via PC and the SIMPLEHOME/RS232 NEW INSTALLATION: allows creation of a new converter connected to the home automation bus, system by entering basic information.
  • Page 52 Before you can use the software, certain information must be entered as correct operation cannot be guaranteed without it: AVAILABLE COMMANDS Select the serial port on the PC to which the SIMPLEHOME/RS232 interface is connected (*) Set the name to be entered for program access at startup Set the password to be entered for program access at startup Set the module range, with a default option suggested by the "SEARCH MODULES"...
  • Page 53 NEW INSTALLATION After clicking on the command, the following screen will appear: To continue, you must fi ll in all the fi elds (these are required to make the system unique and traceable). At this point, if everything has been entered correctly, confi rm by clicking "Create", or cancel everything and return to the main screen by clicking "Exit".
  • Page 54 DIGITAL AND ANALOGUE MODULE TEST While the system is running and communicating with the PC via the SIMPLEHOME/RS232 connection interface, click on the command to make the following window appear: AVAILABLE COMMANDS Select the serial number of the module you wish to test...
  • Page 55 This function is used to change the serial number of individual devices in the system which is running and connected to the PC via the SIMPLEHOME/ RS232 interface, without having to lock or disassemble the system. The reprogrammed device will keep running in accordance with the settings made previously (inputs, outputs and scenarios), but its serial number will be different.
  • Page 56 SEARCH MODULES While the system is running and communicating with the PC via the SIMPLEHOME/RS232 interface, this function can be used to query a group of serial numbers and for each one indicate whether a module is associated with it; if so, its main features are listed, namely the model, fi rmware version, inputs and outputs.
  • Page 57 Once you have fi nished confi guring the system modules according to the instructions provided in the chapter “TREE MENU SCREEN AND MODULE PROGRAMMING” and the system is capable of communicating with the PC via the SIMPLEHOME/ RS232 interface, this command can be used to transfer programming to the system.
  • Page 58 QUERY MODULES While the system is running and communicating with the PC via the SIMPLEHOME/RS232 interface, this function can be used to load the current system confi guration into the software, for example to modify it and download it onto another SIMPLEHOME system.
  • Page 59 PRINT Used to print a hard copy of the confi guration currently on the PC, using the printer set by default in the "Printers" folder in Windows. AVAILABLE COMMANDS Print setup Exit the "PRINT" function and return to the main screen Select the initial serial number for printing Select the serial number for printing...

  • Page 60: Tree Menu Screen And Module Programming

    3.3 - TREE MENU SCREEN AND MODULE PROGRAMMING AVAILABLE COMMANDS Save confi guration Serial number programming Exit the current window and return to the main Print setup screen...
  • Page 61 To create the fi rst confi guration for the system, proceed as follows: 1) After fi tting the bus line and connecting the SIMPLEHOME/RS232 interface to the bus on one side and to the PC on the other, remove the bus terminals from all the modules so that when programming begins none of the modules are connected, apart from the power supply units;...
  • Page 62 7) in the following window, enter 1 in the "Current serial number" fi eld, and the number you wish to assign to the device in the "New serial number" fi eld; at this point, click the "Program" button: 8) return to the tree menu screen and click on the device being programmed again: it will now be possible to confi gure the inputs, scenarios and other parameters in accordance with the on-screen instructions and rules provided directly by the software (if they do not appear, click the "Help"...
  • Page 63 To modify the confi guration of a previously archived system, proceed as follows: command 1) while the system is running and connected to the PC via the SIMPLEHOME/RS232 interface, click the “OPEN INSTALLATION” on the main screen; 2) at this point the "tree menu screen" will appear, showing the current programming: click on the module you wish to reprogram and the device confi guration window will appear;...

  • Page 64: Module Programming

    3.4 - MODULE PROGRAMMING The settings and programmable operating modes are listed below, according to the type of module to be confi gured. Digital modules GENERAL PARAMETERS indicates the module address or the serial number assigned by SimpleProg. Serial number assignment takes place MODULE NUMBER: using the software with the "Serial number programming"...
  • Page 65 will be deactivated 2 seconds after the command is received. indicates the delay between activation of one output and the the next on receipt of a zone command controlling OUTPUTS DELAY: several outputs belonging to the same module. For example, if you order a module to deactivate all outputs with a zone command and a delay of 2 seconds has been set, the fi rst output will be deactivated, then the second 2 seconds later and so on.
  • Page 66 the lights, and then an input set as "Zone" in the message addressee fi eld, entering zone number 5. the function enables control of several outputs on different modules. This setting is used to send a command which switches ZONE: off all the lights in an apartment or lowers all the shutters, etc...
  • Page 67 DIGITAL OUTPUTS set this option if the output needs to be activated when the input closes, and deactivated when the input opens. Every MONOSTABLE: time the input opens or closes, a SET or RESET command is sent. This function can be used for the outputs to which a ringtone is connected, such as a bathroom pull-cord or doorbell.
  • Page 68 this option is used to connect timed procedures such as the stair light, outputs for the irrigation valve, a hallway light or other TIMED: functions. When a button confi gured to control the timed output is pressed, the output is activated and then, once the time has elapsed, deactivated.
  • Page 69 SCENARIO INPUT The scenario input, present on all modules with digital inputs, can be used to send 8 different commands over the BUS. For example, it is useful if you want to switch off all the lights in the home, lower all the rolling shutters, deactivate the controlled sockets, etc... In this case, several commands are required and sent over the BUS;...
  • Page 70 Pulse meter module INPUTS enter a description of the device connected to the input. INPUT DESCRIPTION: set meter input if the pulse meter input is used. FUNCTION: enter the number of pulses which will cause the meter value to rise. PULSES PER INCREMENT: enter the value to be added to the meter for each step.
  • Page 71 The analogue inputs are usually used for the connection of sensors with a 0-10 V output, such as brightness level sensors, humidity sensors, temperature sensors, etc... The only device integrated into the Comelit system capable of providing a 0-10 V signal is the temperature sensor 20046708.
  • Page 72 this tick can be used to set re-transmission of the command in the event that the module under control ENABLE MESSAGE RETRY: does not respond. Under normal conditions, a single command is suffi cient to control the output. If the message is not received by the module, and therefore the module sending the command does not receive feedback that the command has been carried out successfully, the command will be sent again up to a maximum of 3 times.
  • Page 73 normal button connected to a digital input on a module. If "Dimmer" mode is set, you will also need to set the "Start dimmer" value. The "Start dimmer" value can be set between 0 and 255, and corresponds to the 0-10 V output value converted to 8-bit format. It enables the setting of a minimum value for the 0-10 V output; the output will never be adjusted under this value.
  • Page 74 Climate control 20004100 SENSOR CLIMATE ZONES, Minitouch Thermostat. enter a description of the climate room which appears on the supervisor. THERMOSTAT DESCRIPTION: this fi eld indicates the module number and the output number to control in order to make the WINTER - SUMMER STATUS OUTPUT: climate zone switch automatically between winter and summer modes.
  • Page 75 a zone number can be assigned to one of the 2 summer or winter setpoints. This means it is possible, ZONE FOR WINTER - SUMMER SET: by closing a digital input for example, to set the same mode on all thermostats or Minitouch units in the system. indicates the time in seconds required to send setpoints and temperature settings entered on the Minitouch over the BUS.
  • Page 76 Load management module...
  • Page 77 if the power setpoint is exceeded for the "Delay sending deactivation command" indicated in the advanced settings, the TIMED CUT-OFF: module begins to cut off the loads entered on the list. Immediate cut-off: if the power setpoint is exceeded, the module cuts off all loads entered on the list. After any type of cut-off the module begins counting down a time period set in the "Time OFF"...

  • Page 79: Adding A Planux Manager / Minitouch Module

    3.5.1 - ADDING A PLANUX MANAGER / MINITOUCH MODULE Caution: the entire system must have been confi gured before programming the Planux Manager / Minitouch. 1. Open the fi le corresponding to the desired system. 2. Right-click on the Supervisor icon. 3.

  • Page 80: Adding / Removing Simplebus Modules

    3.5.2 - ADDING / REMOVING SIMPLEBUS MODULES To add a module (e.g. Art. 1256, Art. 1259): 1. Press Add Simplebus module. 2. Select the type of module you wish to add (an actuator, for example). 3. Set the module address (e.g. 3). 4.

  • Page 81: Adding / Removing A Planux Manager Or Minitouch

    Master/Slave: Set the monitor as master or slave. On-board thermostat: Set the SimpleHome address of the thermostat on board the Minitouch. This address should only be set from this menu and must not be addressed in any other way. If set to "Not visible", the climate zone controlled by the thermostat on board the Minitouch will not be displayed.

  • Page 82: Configuring A Minitouch Thermostat

    3.5.4 - CONFIGURING A MINITOUCH THERMOSTAT Thermostat description: enter a description of the climate zone which appears on the supervisor. Winter/Summer status output: this fi eld indicates the module number and the output number to control in order to make the Mintouch switch automatically between winter and summer modes.
  • Page 83 if the temperature measured in the room is between 22°C and 21°C; if the temperature is between 21°C and 20°C, speed level 2 will be activated and if the temperature measured is lower than 20°C speed level 3 will be activated. On-Board Outputs: set this option if you want to use the on-board outputs, the control relay for a climate zone (boiler or electrovalve) and the 3 potential speed levels for the convector heater.

  • Page 84: Adding / Removing Home Automation Rooms

    3.5.5 - ADDING / REMOVING HOME AUTOMATION ROOMS To add a home automation room (these rooms are the same ones entered when adding a supervisor): 1. Press Add Room. 2. Enter the name you wish to assign to the room. 3.

  • Page 85: Adding / Removing Alarm Areas

    3.5.6 - ADDING / REMOVING ALARM AREAS To add an alarm area: 1. Select the alarm control panel (e.g. Vedo68). 2. Press Add in the Areas section. 3. Enter the name you wish to assign to the area. 4. Press OK to confi rm. To remove an area: } Press Remove in the Areas section.

  • Page 86: Adding / Removing Alarm Zones

    3.5.7 - ADDING / REMOVING ALARM ZONES To add an alarm zone: 1. Select the type of zone you wish to add (Radio or Wired). 2. Press Add in the Zones section. 3. Enter the number in line with the wiring to the alarm control unit. N.B.
  • Page 87 1. Select the area to which the confi gured zone should be assigned. To remove a zone: 1. Select the type of zone you wish to remove (Radio or Wired). 2. Press Remove in the Zones section. 3. Enter the number corresponding to the zone you wish to remove. 4.

  • Page 88: Renaming Alarm Areas / Zones

    3.5.8 - RENAMING ALARM AREAS / ZONES To rename an alarm area or zone: 1. For zones only, select the type (RADIO or WIRED). 2. Press Rename in the Zones or Areas section. 3. Enter the number of the zone or area you wish to rename. 4.

  • Page 89: Managing System Modules

    3.5.9 - MANAGING SYSTEM MODULES All installed modules are managed on the "Modules" tab. The editable cells on this screen will be highlighted in yellow. N.Mod This column indicates the number assigned to the module within the system. N.In This column indicates the number of the input used on the module. N.Out This column indicates the number of the output used on the module.
  • Page 90 Currency Set the currency used when metering consumption on the supervisor. Group Different energy meter modules can be included in one group to create a single display. For example, in the case of a three-phase system there may be 3 load and consumption control modules; these may be included in the same group in order to create a single chart showing the total of the 3 consumption values on the supervisor.

  • Page 91: Creating A Conditioned Output

    3.5.10 - CREATING A CONDITIONED OUTPUT To use the Conditioned Output function, at least one input on one of the digital modules installed must be set as supervisor. The conditioned output makes it possible to stop the timers set for that output on the supervisor, depending on the status of an input on a digital module set as supervisor.

  • Page 92: Creating A Conditioned Scenario

    3.5.11 - CREATING A CONDITIONED SCENARIO A conditioned scenario is a scenario sent by a supervisor and applied when the input associated with it opens or closes. To create a Conditioned Scenario, at least one digital input on one of the modules installed must be set as supervisor. The scenario is activated and confi...
  • Page 93 3. Select the activation time. » The scenario will be activated when the sensors remain in the set status for longer than the specifi ed time period. 4. Select the operator (OR / AND). » If the operator OR is selected, the scenario will be activated when even just one of the wired / radio zones remains in the set status for longer than the specifi...

  • Page 94: Creating The Supervisor Configuration File

    5. Select the wired / radio zones and the status to be linked with the scenario. In the case of the scenario that has just been created: » The name of the scenario appearing in the list of conditioned scenarios on the Planux Manager / Minitouch monitor will be "Alarm Scenario".
  • Page 95 3. Select which confi guration to export. For example, only from one of the Planux Manager or Minitouch devices in the system. 4. Press Export. 5. Select the export directory (for example, the SD or MiniSD card inserted in supervisors). 6.
  • Page 96 If there is already a folder called confi g in the selected directory: A Overwrite the existing folder B Repeat the export procedure, selecting a different directory. » The text "Export successfully completed!" will appear. 1. Press OK. If the SD card has not been selected as the export directory: 1.

  • Page 97: Adding A One - One/E Module

    3.6 - ADDING A ONE - ONE/E MODULE Caution: the entire system must have been confi gured before programming the One module. 1. Open the fi le corresponding to the desired system. 2. Right-click on the One icon. 3. Left-click on the Add button. 4.

  • Page 98: General One - One/E Module Parameters

    3.6.1 - GENERAL ONE - ONE/E MODULE PARAMETERS GENERAL PARAMETERS indicates the module address or the serial number assigned by SimpleProg. Serial number assignment is carried MODULE NUMBER: out using the dip switch on the back of the ONE module. indicates a general description of the module, where you can enter the installation point or general function of that DESCRIPTION: module.

  • Page 99: Customising The One - One/E Module

    3.6.2 - CUSTOMISING THE ONE - ONE/E MODULE CUSTOM SETTINGS this menu can be used to load / delete a previously saved graphics view, save a new one or save any changes GRAPHICS VIEW: made to the one that is currently open. By graphics view we mean the button layout on the various One device screens and the colours associated with them.

  • Page 100: Configuring One Module Screens

    3.6.3 - CONFIGURING ONE MODULE SCREENS The ONE control device has 3 screens that can be programmed with 3 different functions: • Automation management • Scenario management (max. 1 screen per device) • Climate management (max. 1 screen per device) 3.6.3.1 - AUTOMATION MANAGEMENT select the Automations function in this menu.
  • Page 101 the supervisor function sends a command directly to the system supervisors, for example Planux Manager, Serial SUPERVISOR: Bridge, Minitouch. This command is used by the supervisors to activate internally stored commands, or to use the input status for logic rules or other functions. You must set the number of the supervisor input to send. For example, if you want to use a button to activate a scenario stored in the memory of a Planux Manager or Minitouch supervisor, you must set the input in this way.
  • Page 102 3.6.3.2 - SCENARIO MANAGEMENT The scenario input can be used to send 16 different commands over the BUS. For example, it is useful if you want to switch off all the lights in the home, lower all the rolling shutters, deactivate the controlled sockets, etc... In this case, several commands are required and sent over the BUS;...
  • Page 103 TYPE OF MESSAGE the module sends a command to the addressee, controlling the output for which it was programmed. NORMAL: For example, if you send a normal command to a timed output, the output will be activated for the set time; if you send a normal command to an output set as bistable, the output inverts its status.
  • Page 104 Winter/Summer status output: this fi eld indicates the module number and output number required to display the type of operation set for the climate zone. If the climate zone is set to winter mode, the output is disabled; if on the other hand the zone is set to summer mode, the output is enabled.

  • Page 105: Configuring One/E Module Screens

    3.6.4 - CONFIGURING ONE/E MODULE SCREENS 3.6.4.1 - AUTOMATION MANAGEMENT this drop-down menu can be used to specify what is to be shown on the display: a button or arrows (sector 2 only). COMMANDS: this menu changes depending on the number of buttons or arrows selected in the previous step. COMMAND CONFIGURATION: INPUT DESCRIPTION Field used to enter a short description of the function or the module managed by the button/arrow.
  • Page 106 the supervisor function sends a command directly to the system supervisors, for example Planux Manager, Serial SUPERVISOR: Bridge, Minitouch. This command is used by the supervisors to activate internally stored commands, or to use the input status for logic rules or other functions. You must set the number of the supervisor input to send. For example, if you want to use a button to activate a scenario stored in the memory of a Planux Manager or Minitouch supervisor, you must set the input in this way.
