Service Manual
Steps
4. Remove the cabinet
Remove the connecting screws fixing the
cabinet. Remove the cabinet.
5. Remove right side plate subassembly
Remove the screws fixing the right side plate.
Remove the right side plate.
6. Remove electric box subassembly
Remove the screws fixing the electric box
cover. Disconnect the wire terminals and
remove the electric box.
Procedure
cabinet
right side plate
electric box subassembly
73
