Service Manual
At OFF status, press this button once can set TIMER ON. Please refer to TIMER off for detailed operation.
●
Cancel TIMER ON: Press "TIMER" button again under TIMER ON status.
Note:
Time setting range: 0.5-24 hours.
●
Time interval between two operations can't exceed 5s. Otherwise, remote controller will exit the setting status automatically.
●
11. TURBO button
When pressing this button under cooling or heating mode, air conditioner will enter into quick cooling or quick heating mode. The
character of "TURBO" is displayed on remote controller. Press this button again to exit turbo function and the character of "TURBO" will be
disappeared on remote controller.
12. SLEEP button
Press this button under cooling, heating or drying mode can start up sleep function"
this button again to cancel sleep function"
13. LIGHT button
Press this button can turn off the light for indoor unit's display"
on the light for indoor unit's display"

Function Introduction for Combination Buttons

Child lock function:
Press "+" and "-" buttons simultaneously can turn on or turn off child lock function. When child lock function is started up"
displayed on remote controller. If operate remote controller"
Switchover function for temperature display:
After turning off the unit by remote controller, press "-" button and "MODE" button simultaneously to switch between ℃ and ℉ .

Operation Guide

1. After putting through the power, press "ON/OFF" button on remote controller to turn on the air conditioner.
2. Press "MODE" button to select your required mode:AUTO,COOL,DRY,FAN,HEAT.
3. Press "+" or "-" button to set your required temperature. (Temperature can't be
adjusted under auto mode).
4. Press 'FAN" button to set your required fan speed: auto, low, medium and high speed.
5. Press " "button and"

Replacement of Batteries in Remote Controller

1.Press the back side of remote controller marked with"
of battery box along the arrow direction.
2. Replace two 7# (AAA 1.5V) dry batteries, and make sure the position of "+" polar and "-" polar are correct.
3. Reinstall the cover of battery box.
Note:
● During operation, point the remote control signal sender at the receiving window on
indoor unit.
● The distance between signal sender and receiving window should be no more than 8m,
and there should be no obstacles between them.
● Signal may be interfered easily in the room where there is fluorescent lamp or wireless
telephone; remote controller should be close to indoor unit during operation.
● Replace new batteries of the same model when replacement is required.
● When you don't use remote controller for a long time, please take out the batteries.
● If the display on remote controller is fuzzy or there's no display, please replace
batteries.
"icon on remote controller will be displayed.
"icon on remote controller will be displayed.
"button to select fan blowing angle.
"icon will be displayed on remote controller. Press
"icon on remote controller will disappear. Press this button again to turn
"icon will flash three times, while remote controller won't send signal.
"as shown in the fig, and then push out the cover
26
Signal sender
Battery
Reinstall
Cover of
battery box
"icon will be
Remove
