Service Manual
Step
4.Remove guard grille
Twist off the screws used for fixing the guard
grille, pull the guard grille outward and then
remove the guard grille．
5.Remove grille
Twist off the screw used for fixing the grille,
loosen the clasp, pull out the grille outward and
then remove the grille．
6.Remove panel
Twist off the screw used for fixing the outer case,
pull the panel outwardand then remove the panel．
Procedure
grille
panel
67
guard grille
