11.2 Removal Procedure of Outdoor Unit
MUCO-48-H6T
Step
1.Before disassembly of unit
2.Remove top panel
Twist off the screws used for fixing the top cover
with screwdriver, lift up the top cover and then
remove the top cover．
3.Remove front side plate
Twist off the screws used for fixing the front side
plate, pull the front side plate forward and
outward and then remove the front side plate．
Procedure
top panel
front side plate
66
Service Manual
