Service Manual
Description
No.
Product Code
1 Rear Plate Assy
2 Left Side Plate Sub-Assy
3 Right Side Plate Sub-Assy
4 Top Cover Sub-Assy
5 Breakwater Sub-Assy
6 Evaporator Assy
7 Capillary Sub-assy (Heating)
8 Ambient Temperature Sensor
9 Crank
10 Rear Grill
11 Electric Heater
12 Step Motor
13 Step Motor
14 Swing Lever
15 Guide Blade Lever
16 Display Board
17 Propeller HousingPress Plate Sub-assy
18 Air Guard Assy
19 Latch
20 Air Outlet Panel Assy
21 Air Intake Panel Assy
22 Filter Sub-Assy
23 Electric Box Cover Sub-Assy
24 Main Board
25 Capacitor CBB61
26 Terminal Board
27 Transformer
28 Electric Box Assy
29 Protective Covering
30 Diversion Circle
31 Propeller Housing Sub-assy
32 Centrifugal Fan
33 Fan Motor
34 Chassis
35 Water Tray Sub-Assy
36 Baffle Plate
37 Rear Cover
38 Connecting Cable
Above data is subject to change without notice.
Part Code
MUCO-60-H6T
UI20391
01304500
0130451901
0130451801
22244152
01364503P
011001000168
030006000230
3900019003
73014023
01474057
32004124
1521401601
1521400803
10584218
10584089
30563195
01384061
01364509
70810302
008014000020
20004536
11124100
01404388
300002000040
/
42010052
43110287
100002000367
01474027
10374435
12104058
10314401
1501442502
22224020
12314811
2611454401
2224422201
400205396
54
Qty
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
3
3
1
