Step
13.Remove gas and liquid separator
Loosen the two screws used for fixing the gas
and liquid separator, pull it upward and then
remove the gas and liquid separator.
14.Remove compressor
Twist off the nuts used for fixing the compressor
withwrench, pull the compressor upward to
remove it.
15.Remove middle isolation sheet
Twist off the screws used for fixing the middle
isolation sheet, pull it upward and then remove
the isolation sheet.
Procedure
70
Service Manual
gas and liquid seperator
compressor
isolation sheet
