mundoclima MUCO-H6T Service Manual page 56

Service Manual
Description
No.
Product Code
1 Front Grill
2 Left Handle
3 Cabinet
4 Axial Flow Fan
5 Fan Motor
6 Motor Support
7 Ambient Temperature Sensor
8 Sensor Support
9 Condenser Assy
10 Coping
11 Clapboard Sub-Assy
12 Rear Grill
13 Rear Side Plate Sub-Assy
14 Outdoor Tube Sensor
15 Handle
16 Assistant Capillary Sub-Assy
17 4-Way Valve Assy
18 Magnet Coil
19 Pressure Protect Switch
20 Inhalation Tube Assy
21 Pressure Protect Switch
22 Air-out Temp Sensor
23 Cut off Valve Sub-Assy
24 Valve Support Sub-Assy
25 Gas Valve Sub-Assy
26 Compressor and Fittings
27 Capacitor CBB61
28 Terminal Board
29 Over Current Protector
30 Terminal Board
31 Anti-phase Protector
32 AC Contactor
33 Electric Box Assy
34 Chassis Sub-assy
35 Drainage Connecter
36 Drainage Hole Cap
37 Front Side Plate Sub-Assy
38 Electrical Heater
Above data is subject to change without notice.
Part Code
MUCO-48-H6T
UE20390
01475401
26235401
01435103P
10335401
15010100000101
01705401
39000199
24215101
011002000212
01255012P
01235403
01473003
01303290
39000194
26235253
03133489
030152000131
4300040022
4602000603
03735085
46020007
39000163
07130212
01715402
/
00105065
3301074705
42010052
46020112
42011103
46020052
44010226
100002000129
012054026P
06123401
06813401
01305507
7651540413
56
Qty
1
1
1
1
1
1
1
1
1
1
1
1
1
1
2
1
1
1
1
1
1
1
1
1
/
1
1
2
1
2
1
1
1
1
1
2
1
1
