Service Manual
Steps
Procedure
12. Remove chassis
Remove the screws fixing chassis to remove
the chassis.
chassis
13. Remove left side plate and right side plate
left side plate
right side plate
Remove the screws fixing left side plate and
right side plate to remove the left side plate
and right side plate sub-assy.
65
