Service Manual
4. Refrigerant System Diagram
Indoor unit
Heat
exchanger
(evaporator)
Connection pipe specification:
Liquid pipe:1/2" (12mm) Gas pipe:3/4" (19mm)
Gas pipe
side
Valve
Di s charge
Suction
Compressor
Liquid pipe
side
Valve
Strainer
12
Outdoor unit
4-Way valve
Accumlator
Heat
exchanger
(condenser)
Capillary
Strainer
COOLING
HEATING
