Your Synectix VMS Lite shipping carton must contain the following:

The Synectix VMS Lite Unit

This User Manual

Phone Line Cords

RPI software installation CD

Power Adapter

Serial Programming cable

Select a suitable location for the Synectix VMS Lite to be placed - it may be wall

mounted or kept on the tabletop. A suitable location should have 2 analog phone

extension sockets for the system, preferably another phone for testing and a power

socket close by and should be easily accessible for any service or maintenance work.

If you plan to mount the unit on the wall please follow the wall mounting instructions

given below:

Use the paper template, provided with the unit and secure two wood screws (Size 5 or

6) into the wall where you want to mount the unit. The distance between the center

points of the mounting screws should be 3 inches. The wall on which the unit is to be

mounted should be strong enough to support the weight of the unit. Also make sure

that the screws are driven securely into the wall. Then, hang the unit onto the screws.

Plug in the Power Adapter into the Power socket and switch on the power to the unit.

The Power lamp on the unit starts glowing steadily, then all the 2 Port LED's flash on

and off twice and after about 5 seconds the Power LED continues to flash once a

second, indicating normal operation.

Insert the phone line cords into the phone sockets on the unit and insert the other end

into the wall extension sockets for the 2 ports.

You are now ready to do a Functional Check of the unit.

After the Installation has been completed satisfactorily, you should carry out a few

preliminary checks, before putting the unit into operation.

If you are looking at the Synectix VMS Lite while you are running the functional check,

it is very easy to solve any problems that may be encountered as well as understand

the programming methods.

You will need another extension with a phone from which you can call into the

Synectix VMS Lite to go through the functional check. Ascertain the extension

numbers of the Synectix VMS Lite and call into it from the phone. The unit should pick

up the call after the second ring and start playing the Main greeting.

If the Synectix VMS Lite does not pick up the call, check the extension into which the

Synectix VMS Lite is plugged in by plugging that extension into a regular phone
