Cygnus 1 Operation Manual page 80

Logging Readings to a Grid-Point File
The next Reading to be logged is the highlighted Reading in the list, and the number of this
Reading appears in the
click on the Log button to log the currently displayed Reading :
the new value will now appear in the list, and will overwrite any existing value
the highlighted Reading will now become the next reading, and the number in the
Log Reading
values in the
Tip : you can click Back to return to the previous Reading if you wish to change the
value which has just been logged
Tip : use the scrollbar in the reading-list to scroll to any reading-number in the list, and
then click on the new Reading : the new Reading will be highlighted, and the new
number will appear in the
When all required Readings in the current list have been obtained :
move on to the next list using the appropriate Row or Column slider in the
Position
box
Reading Summary
a new
Log Reading
box :
box will increment
Reading Summary
Log Reading
will appear each time a new list is selected
box will be updated, showing the new summary
box
Remote-Logging
Grid
79
