Cygnus 1 Operation Manual page 63

Creating a new Grid-Point File
Enter Filename and Dimensions :
Filename to be sent to Gauge
Click in the
long, made up of numbers and letters.
This is the name that will appear on the Gauge
click on the desired button for the
CygLink will automatically switch to measure in these units when this file is in use
Number of Rows
Click in the
Number of Columns
Click in the
Number of Readings
Click in the
Select Preferred Working Axis - choose the working axis best suited to the physical situation
where the Measurements will be taken :
Either : select
of Measurements on a horizontal axis, before moving on to the next Row
Take Measurements down Columns
Or : select
of Measurements on a vertical axis, before moving on to the next Column
Enter optional Alarm values :
Optionally : click in the
75 mm [or between 0 and 3 inches, if units are set to inches]
Set the value to 0 if Reference Thickness is not required
Optionally : enter Alarm percentages based on the Reference Thickness value
either an Upper Tolerance, or a Lower Tolerance, or both may be entered
Set either value to 0 if not required
Open an existing Grid-Point File
An existing Grid-Point file can be used as a template to create new files :
Click on the Open button
Open Grid-Point File
The
Navigate to the location of the existing Grid-Point file required, and then double-click
on the filename
The file will open and its values will be copied into the boxes in the
Point File
window : edit the Filename and Dimensions if required
Save and close the new File
Click on the Save As button to save this new File :
Save Multi-Record File
The
Click the Save button to save the suggested filename into the current directory
Or : change the Filename and/or Directory if desired, then click Save
The new file is now saved to disk, ready for use in a new datalogging session
box, then enter a number between 1 and 100
Take Measurements across Rows
Reference Thickness
dialog window will open :
dialog window will open :
Creating Template-Files Using CygLink
box, then enter a name up to 8 characters
Measurement Units
box, then enter a number between 1 and 100
box, then enter a number between 1 and 10
– the Datalogger will make each set
– the Datalogger will make each set
box, then enter a number between 0 and
Create a Grid-
