Cygnus 1 Operation Manual page 33

Echo-Strength Bargraph
The green bargraph display indicates ultrasonic coupling-strength :
A single flashing bar means there is no contact at all
One or two bars, plus a flashing bar, means there is not enough contact to obtain three
echoes
This indicates either poor contact, or badly corroded material
This can also occur if the Probe membrane has been fitted incorrectly
Three bars, plus one flashing bar, means there is good contact, but a valid triple-echo
measurement has not been obtained
This probably indicates badly corroded material
Four bars, plus one flashing bar, shows an accurate triple-echo measurment
Measurement Units
CygLink is able to display Measurement in either Metric or Imperial units :
Click on the on-screen Units switch button to toggle between Metric [
inch
[ ] units.
Readings will stored in the Log-File in the same Units as the current on-screen
Measurement display
CygLink saves the current Units-setting, so that the same Units will be displayed next
time CygLink is started
Display Selector
Display
The box normally has the
display is showing the Current Reading
Calibration is achieved by clicking on one of the other options in the Display box – the
large-reading display is then used to provide Calibration :
Calibration
Click on
Velocity
Click on
Material
Click on
See : Calibrating the Gauge, page 36
Lost Datalink
If the connection from the Gauge to the PC should be broken during normal operation a
Remote Gauge Error
Timeout
will appear in the CygLink main window :
If the problem is temporary and clears itself, the message box will automatically
disappear
Otherwise click OK to close the message box – the message box will not reappear in
this session of operation, but the Red indicator and
until the connection has been re-established
Measurement
: to Calibrate by adjusting the displayed reading using the slider
: to Calibrate by adjusting the Velocity of Sound using the slider
: to Calibrate by selecting the Material from a list
message box will pop-up, and a Red indicator with the message
Viewing Measurements on the PC
option selected so that the large-reading
Link Timeout
mm
] and Imperial
Link
message will remain
32
