Cygnus 1 Operation Manual page 59

To Add new Key-Point Records
Move the slider down to the bottom :
Next Record
The
Total Records
the current
Nothing will be highlighted in the Record-list box, because a new Record is to be added
to the end of the list
Enter a name for the next Record :
Edit a name for the next Record
Click in the
characters, made up of letters, numbers, spaces and hyphens
Or : click in the box and edit the existing name
Enter optional values for the current Key-Point Record, or else leave as default :
Optionally : click in the
This is the least number of Readings which must be taken at this Key-Point
Optionally : click in the
75 mm [or between 0 and 3 inches, if units are set to inches]
Set the value to 0 if Reference Thickness if not required
Optionally : enter Alarm percentages based on the Reference Thickness value
Upper Tolerance
Either an
Set either value to 0 if not required
Add the new Record to the list :
When all of the values desired values have been entered click on the Add button
The Key-Point Record will be added to the list,
the Next Record pointer will increase by one,
and the Total Records counter will increase by one
Use the scroll bar to change the
the new Record will be inserted into the list at this location
the Record numbers in the list will all be automatically adjusted
the Next Record pointer will increase by one, to continue inserting Records from this
point onwards
Keep adding new Records :
Repeat the above to keep entering new Key-Point Records, pressing Add for each new
Record
Key-Point Records can be added up to a maximum of 999 Records
Click Save As at any time, to save the current editing session
Or : Click Quit to end the editing session, and close the
window
box will show that the next Record is to be numbered one more than
value
Number of Readings
Reference Thickness
Lower Tolerance
, or a
Next Record
Creating Template-Files Using CygLink
box, then enter a name of up to 16
box, enter a number between 1 and 100
box, then enter a number between 0 and
, or both may be entered
counter – when the Add button is pressed
Create a Key-Point File
