REMOTE-LOGGING TO DATALOGGER FILES

With a Gauge connected to the PC, Readings can be logged directly to any of the
Datalogger file-types which are created using CygLink :
Logging to a Single-Record File, page 69
Logging to a Multi-Record File, page 71
Logging to a Key-Point File, page 72
Logging to a Grid-Point File, page 74
The logging session is managed the same way in all cases :
Gauge to PC Connection
If a Gauge is currently connected to the PC : the Log button will be enabled
If there is no connection, or if the connection becomes lost : the Log button will be
greyed-out, and Readings cannot be logged
The current Reading received from the Gauge is shown in the
if there is currently no connection with the Gauge then No Link will be displayed
instead
Saving the current logfile
The current logging session may be saved at any time :
Click on the Save As button :
Save updated Single-Record File
the
either : click Save to update the existing file, and then continue using this file
or : enter a new filename, and then click Save :
the existing file will be closed without being updated, and logging will continue to
the new file, with the new filename appearing in the
Creating a Report
A new Report file may be created at any time during the current logging session :
The Report will include all logged Readings, including any Readings from the current
session which have not yet been saved - see : Creating a Report File, page 48
Finishing the Logging session
Click on the Done button to end the logging session :
If there are logged Readings which have not yet been saved a pop-up will appear
prompting you to save :
click No to quit without saving
click Yes to save :
Save updated Single-Record File
the
either : click Save to save and update the existing file
or : enter a new filename, and then save to the new file
window will open :
Filename
window will open :
Remote-Logging
Log Reading
box :
box
68
