Logging Readings to a Key-Point File
The next Reading to be logged is the highlighted Reading in the list, and the number of this
Reading appears in the
click on the Log button to log the currently displayed Reading :
the new value will now appear in the list, and will overwrite any existing value
the highlighted Reading will now become the next reading, and the number in the
Log Reading
values in the
Tip : you can click Back to return to the previous Reading if you wish to change the
value which has just been logged
Tip : use the scrollbar in the reading-list to scroll to any reading-number in the list, and
then click on the new Reading : the new Reading will be highlighted, and the new
number will appear in the
After a value has been logged to the last Reading in the current Record :
an extra Reading-number will appear in the list, with the value add?
this allows extra Readings to be freely added to the current Record, up to a limit of 100
total Readings within the current Record
Click on Log to continue adding Readings to the current Record
When all required Readings in the current Key-Point Record have been obtained, use the
Key-Point Record Number
controls in the
move on to the next Record in the file using the Next button in the
Number
box
use the Back button or the scrollbar to choose any other Record from the file
Reading Summary
a new
Log Reading
box :
box will increment
Reading Summary
Log Reading
will appear each time a new Record is chosen
box will be updated, showing the new summary
box
box to select the next Record :
Remote-Logging
Key-Point Record
74
