Verify a valid network path exists between the RemotEye III and the workstation. If performing the Telnet
configuration from a workstation that is located on the same network, then proceed to the next section "
Connecting to the RemotEye III via Telnet" on page 37.
Routing to the RemotEye III
If the workstation is not on the same network as the RemotEye III, the system may require the addition of a network
route. This is typically only necessary when RemotEye III is using its default address.
Consult operating system documentation pertaining to the addition of network routes for instruction.
Example Route Addition
Windows operating systems provide the command Route Add for adding network routes.
Assume the default IP Address of the RemotEye III is 172.18.1.63, and assume the IP Address of the workstation is
210.67.192.147. To add the appropriate network route between these two devices, follow these steps:
Turn on the workstation, and setup the TCP/IP protocol (if necessary).
Enter the following command to add a routing condition (e.g. Command Prompt in Windows OS):
Route add 172.18.1.63 210.67.192.147
See the Windows manual for further information on how to add a routing condition to a workstation.
Connecting to the RemotEye III via Telnet
A telnet configuration session can be established once the hardware and software are prepared. Open the Telnet
application software and follow these steps to begin configuration:
1.
Type telnet followed by the IP address of RemotEye III to a telnet application (e.g. telnet 192.168.1.50).
2.
Press [Enter].
3.
Key in the password when prompted.
Default Password (case sensitive): ADMIN
For more information on using telnet, please refer to telnet application Windows help.
The RemotEye III will only accept 2 telnet clients simultaneously. The telnet connections will time-out after
60 seconds of inactivity.
RemotEye III Telnet Menu Navigation
The configuration menus for telnet configuration are identical to those presented by a direct configuration session.
Refer to page 23 for detailed guidance through configuration menus of RemotEye III.
RemotEye III User Manual – 62330-005
37
