PEAK 6320A User's Guide
D
. Switch Function
E. Doze Speed(div by)
Stdby speed (div by)
F. Modem Use IRQ
G. Standby Mode
(*) Remark 1
BIOS Setup
1. Break The External Suspend Switch is "Break"
2. Wake The External Suspend Switch is "Wake"
2. 1 Min Defines the continuous idle time before the
2 Min system entering DOZE mode.
4 Min
6 Min if any item defined in (J) is enabled & active,
8 Min DOZE timer will be reloaded
10 Min
20 Min
30 Min
40 Min
1 Hr
Note: Normally,STANDBY
mode puts the system
into low speed or 8
MHz, screen may be
off depend on (E)
1/8 System full speed could be divided by the
2/8 optional integers, the bigger the number the
3/8 slower the speed under Doze or standby
4/8 mode
5/8
6/8
7/8
8/8
3,4,5,7,9 For external modem, 3 or 4 will be used for
4,10,11,NA card type modem. It is up to card definition.
Default is 3.
1. Disable System will never enter STANDBY mode
2. 10 sec Defines the continuous idle time before the
1 Min system entering STANDBY mode.
10 Min
30 Min if any item defined in (J) is enabled & active,
1 Hour STANDBY timer will be reloaded
2 Hour
20 Min
Note: Normally,STANDBY
mode puts the system
into low speed or 8
MHz, screen may be
off depend on (E)
4- 25
