Peak 6320A User's Guide
COM1 RS232 /RS485/RS422
S4.1
*RS232 OFF
RS485 ON
RS422 ON
COM1 RS232 /RS485/RS422
S4.7
*RS232 OFF
RS485 ON
RS422 ON
Panel Type
SW1.4 SW1.3
On On
On On
On On
On On
On Off
On Off
On Off
On Off
Off On
*Off On
Off On
Off On
Off Off
Off Off
Off Off
Off Off
Panel Director
MPCLK From PCLK
*MPCLK From M
DE From M
*DE From LP
Switches and Connectors
S4.2 S4.3
ON OFF
OFF ON
OFF ON
S4.8
ON
OFF
OFF
SW1.2 SW1.1
On On 1024x768 Dual Scan STN Color Panel
On Off 1280x1024 TFT Color Panel
Off On 1024x768 Dual Scan STN Color Panel:
Off Off 1024x768 Dual Scan STN Color Panel
On On 640x480 Sharp TFT Color Panel
On Off 640x480 18Bit TFT Color Panel
Off On 1024x768 TFT Color Panel
Off Off 800x600 TFT Color Panel
On On 800x600 TFT Color Panel
On Off 800x600 TFT Color Panel
Off On 800x600 Dual Scan STN Color Panel
Off Off 800x600 Dual Scan STN Color Panel
On On 1024x768 TFT Color Panel
On Off 1280x1024 Dual Scan STN Color Panel
Off On 1024x600 Dual Scan STN Color Panel
Off Off 1024x600 TFT Color Panel
SW2.1 SW2.2
ON OFF
OFF ON
X X
X X
S4.4 S4.5
ON OFF
OFF ON
OFF ON
S3.1 S3.2
ON OFF
OFF OFF
OFF ON
SW2.3 SW2.4
X X
X X
ON OFF
OFF ON
S4.6
ON
OFF
OFF
S3.3
OFF
ON
OFF
2-3
