Peak 6320A User's Guide
• J14: FDD Connector
PIN No. Description
1 Ground
3 Ground
5 N/C
7 Ground
9 Ground
11 Ground
13 Ground
15 Ground
17 Ground
19 Ground
21 Ground
23 Ground
25 Ground
27 Ground
29 N/C
31 Ground
33 N/C
• J15: Parallel Connector
PIN No. Description
1 Strobe#
3 Data 1
5 Data 3
7 Data 5
9 Data 7
11 Busy
13 Printer Select
15 Error#
17 Printer Select IN#
19 Ground
21 Ground
23 Ground
25 Ground
Switches and Connectors
PIN No. Description
2 Density Select bit 0
4 N/C
6 Density Select bit 1
8 Index#
10 Motor Enabled A#
12 Drive Select B#
14 Drive Select A#
16 Motor Enable B#
18 Direction#
20 Step#
22 Write Data#
24 Write Gate#
26 Track 0#
28 Write Protect #
30 Read Data#
32 Head Side Select#
34 Disk Change#
PIN No. Description
2 Data 0
4 Data 2
6 Data 4
8 Data 6
10 Acknowledge
12 Paper Empty
14 Auto Form Feed#
16 Initialize
18 Ground
20 Ground
22 Ground
24 Ground
26 Ground
2-9
