Chipset Features Setup Menu

Since the features in this section are related to the chipset in the CPU board and all are
optimized, you are not recommended to change the default settings in the setup table,
unless you know very detailed of the chipset features.
Auto Configuration
SDRAM RAS-to-CAS Delay
SDRAM RAS Precharge Time
SDRAM CAS latency Time
SDRAM Precharge Control
DRAM Data Integrity Mode
System BIOS Cacheable
Video BIOS Cacheable
Video RAM Cacheable
8 Bit I/O Recovery Time
16 Bit I/O Recovery Time
Memory Ho le At 15M -16M
Passive Release
Delay Transaction
AGP Aperture Size(MB)
This section describes features of the Intel 440BX PCIset. If your system contains a
different chipset, this section will bear little resemblance to what you see on your screen.
ADVANCED OPTIONS. The parameters in this screen are for system designers, service
personnel, and technically competent users only. Do not reset these values unless you
understand the consequences of your changes.
